Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2 μH ±20 % 25.5 A Idc DR127-2R2-R
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 8mm |
| Length | 12.5mm |
| Model | DR127-2R2-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS |
| Package/Case | 0127 |
| Maximum DC Current | 25.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 4.02mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a ferrite core to enhance magnetic efficiency.
- Features a magnetically shielded wirewound design.
- Surface mount termination style suitable for automated PCB assembly.
- Operates reliably from -40°C to 125°C maximum temperature.
- Inductance tolerance is ±20 % to meet varied circuit requirements.
- Complies with RoHS standards ensuring environmental safety.
- Maximum DC resistance is 4.02 mΩ to minimize power loss.
- Available in a 0127 package with dimensions of 12.5 x 12.5 x 8 mm.
Product Description
Eaton DR127-2R2-R Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2 μH ±20 % and 25.5 A Idc is a high-performance wirewound inductor designed for surface mounting on PCBs. Its ferrite core construction provides enhanced magnetic properties and the magnetic shielding reduces electromagnetic interference, making it suitable for sensitive electronic circuits. This product supports a maximum operating temperature of 125°C and a minimum operating temperature of -40°C.
The inductor’s low DC resistance of 4.02 mΩ ensures high efficiency with minimal power loss. Its inductance tolerance of ±20 % allows flexibility for various electronic applications. Packaged in a 0127 case (12.5 mm length, 12.5 mm depth, and 8 mm height), it is conveniently supplied on reels for streamlined manufacturing processes.
This inductor belongs to Eaton’s DR series, widely used in applications such as computers, DVD players, portable devices, LCD panels, DC-DC converters, including buck, boost, forward, and resonant converters. Its wirewound construction and ferrite core enable noise filtering and efficient signal processing in power electronics.
The device complies with RoHS standards, ensuring environmentally friendly manufacturing and safety. With a pin count of 2 and a molded construction, it offers robust mechanical stability for industrial and commercial electronic device assembly.
Constructed with a ferrite core for improved magnetic performance. Magnetically shielded wirewound design minimizes electromagnetic interference. Surface mount type eases PCB mounting and assembly. Operates within a temperature range of -40°C to 125°C.
Inductance value of 2.2 μH with ±20 % tolerance. Maximum DC current rating is 25.5 A. Low DC resistance of 4.02 mΩ ensures energy efficiency. Complies with RoHS environmental and safety standards. Dimensions: 12.5 mm length, 12.5 mm depth, 8 mm height.
Supplied on reels for manufacturing convenience.
Ideal for industrial, commercial, electronic, and manufacturing sectors requiring reliable inductors for noise filtration and power management. Browse our Electronics Components and Surface Mount Inductors categories for a wide selection of inductors from Eaton and other leading brands at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 2.2 μH with an inductance tolerance of ±20%.
The maximum DC current rating for this inductor is 25.5 A.
It has dimensions of 12.5 mm in length, 12.5 mm in depth, and 8 mm in height.
This inductor operates reliably within a temperature range of -40°C to 125°C.
It features a surface mount termination style suitable for automated PCB assembly.
The maximum DC resistance is 4.02 mΩ, which helps minimize power loss.
The inductor is constructed with a ferrite core to enhance magnetic efficiency.
It is supplied on reels for convenience in manufacturing processes.
This model complies with RoHS standards, ensuring environmental safety.
The maximum self-resonant frequency is 100 kHz.
This inductor is suitable for applications such as computers, DVD players, portable devices, and DC-DC converters.
The inductor has a pin count of 2.
