Samtec TMM Series Straight Through Hole Pin Header, 8 Contacts, 2 mm Pitch, 1 Row, Unshrouded TMM-108-01-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | Samtec |
| Orientation | Straight |
| Operating Temperature | -55°C to +125°C |
| Current | 3.9A |
| Model | TMM-108-01-G-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TMM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.5mm |
| Mating Pin Length | 3.2mm |
| Insulator Material | Black LCP |
Key Features
- Constructed with black Liquid Crystal Polymer housing for durability.
- Contacts are made from phosphor bronze with gold plating for superior conductivity.
- Supports a maximum current of 3.9A and voltage of 500V.
- Tail pins measure 3.5 mm in length facilitating secure solder termination.
- Operating temperature ranges from -55°C to +125°C, suitable for harsh environments.
- Designed with a low profile 2.77 mm height for compact PCB designs.
- Connector system supports both board-to-board and wire-to-board applications.
- Mount type is through hole allowing robust mechanical mounting on PCBs.
Product Description
The Samtec TMM-108-01-G-S is a Straight Through Hole Pin Header from the TMM Series, designed for high reliability in electronics applications. This connector features a low profile 2 mm pitch with 8 male contacts arranged in a single unshrouded row, making it ideal for compact PCB designs requiring precise interconnection solutions.
Manufactured with a housing composed of black Liquid Crystal Polymer (LCP), it provides excellent mechanical strength and heat resistance. The phosphor bronze contacts are gold plated, ensuring high conductivity, corrosion resistance, and longevity even in demanding environments.
This pin header supports a maximum current of 3.9 amperes and operates up to 500 volts, making it suitable for a wide range of industrial and commercial electronic equipment. The tail pins measuring 3.5 mm are designed for solder termination on printed circuit boards, while the mating pins are 3.2 mm long to ensure reliable connections.
Operating temperature capability between -55°C and +125°C allows this connector to perform in extreme conditions commonly encountered in aerospace, automotive, and industrial applications.
The connector system allows use in both board-to-board and wire-to-board setups with a through hole mounting type, providing mechanical stability and ease of installation. Its unshrouded design permits easy access for mating and unmating in assembly and maintenance operations.
This product mates with various Samtec socket series such as SQT, SQW, TLE, SMM, and MMS, giving broad compatibility with complementary components for system integration. Constructed with durable black LCP housing to withstand mechanical and thermal stress.
Gold-plated phosphor bronze contacts provide excellent electrical performance and corrosion resistance. Rated for 3.9A current and 500V maximum voltage suitable for diverse electronic systems. Wide operating temperature range from -55°C up to +125°C for harsh environment tolerance.
Low profile design with 2 mm pitch supports high-density PCB layouts. Through hole mount type ensures robust physical connection to PCB. Compatible with multiple Samtec socket series for flexible application integration.
This Samtec TMM Series PCB header is an optimal choice for industrial, aerospace, automotive, and commercial electronics requiring high quality, reliable signal and power connections on printed circuit boards. Explore the Electronics Components category on EnvMart to find more connectors and related products to complete your system design.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 3.9A, making it suitable for various electronic applications.
It is rated for a maximum voltage of 500V, allowing for use in high-voltage applications.
The housing is made from black Liquid Crystal Polymer, while the contacts are made from phosphor bronze with gold plating for improved conductivity and corrosion resistance.
It operates within a temperature range of -55°C to +125°C, making it suitable for harsh environments.
The tail pins measure 3.5 mm in length, designed for secure solder termination on printed circuit boards.
This connector features a pitch size of 2 mm, suitable for compact PCB designs.
It has 8 male contacts arranged in a single unshrouded row.
It supports through hole mounting, ensuring robust mechanical stability on PCBs.
It is compatible with various Samtec socket series such as SQT, SQW, TLE, SMM, and MMS for flexible application integration.
This model uses solder termination, which is common for secure connections on PCBs.
Yes, it is designed for both board-to-board and wire-to-board applications, providing versatility in electronic designs.
It has a low profile height of 2.77 mm, making it suitable for high-density PCB layouts.
