Wurth Elektronik 4-Element Uni-Directional TVS Diode Array, 6-Pin SOT-23 Package 6.1V Breakdown Voltage 12A Peak 824015

Wurth Elektronik 824015 is a 4-element uni-directional transient voltage suppression (TVS) diode array designed with a 6-pin SOT-23 surface mount package. It features a complex diode array configuration optimized for electrostatic discharge (ESD) protection and transient voltage clamping in sensitive electronic circuits.

This diode array offers a minimum breakdown voltage of 6.1V and maximum reverse stand-off voltage of 5V, providing excellent protection for USB 2.0, HDMI, DVI, Ethernet, and Firewire interfaces. The device supports a high peak pulse current of up to 12A, enabling effective absorption of surge currents during voltage spikes.

Designed for surface mount applications, its compact dimensions of 2.9mm length, 1.6mm width, and 1.06mm height facilitate integration in tight PCB layouts. With an operating temperature range from -55°C to 125°C and low maximum reverse leakage current of 5μA, it guarantees stable and reliable protection under diverse environmental conditions.

The 824015 model belongs to the WE-TVS series, known for ultra-low capacitance devices that minimize signal distortion and enhance signal integrity in high-speed data lines. The 4 elements per chip configuration enables multi-line protection in one component, reducing board space and complexity.

This TVS diode array is widely used in industrial, laboratory, communication, computing, and consumer electronic applications where sensitive interfaces require robust ESD and transient voltage protection to improve device longevity and system reliability.

Package contains the Wurth Elektronik 824015 4-Element Uni-Directional TVS Diode Array in SOT-23 6-pin form factor, ready for surface mounting on printed circuit boards. Features a uni-directional diode configuration ideal for ESD protection.

Minimum breakdown voltage of 6.1V ensures robust transient voltage clamping. Supports a maximum peak pulse current of 12A for high surge capability. Compact surface-mount SOT-23 package with 6 pins for efficient PCB integration.

Operates reliably between -55°C to 125°C ambient temperature range. Low maximum reverse leakage current of 5μA reduces power losses. Designed for protecting interfaces including USB 2.0, HDMI, DVI, Ethernet and Firewire.

Complies with WE-TVS series standards for ultra low capacitance ESD protection devices.
