Preci-Dip 811 Series Straight Surface Mount Spring Loaded Connector, 5 Contacts, 2.54 mm Pitch, 1 Row 811-SS-005-30-003191
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 811-SS-005-30-003191 |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 811 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Provides reliable low resistance electrical connection through spring-loaded contacts.
- Supports a current rating of 3.5A for robust performance.
- Shrouded housing made of fibreglass reinforced polyethylene terephthalate offers durability and insulation.
- Temperature operating range from -55°C to 125°C suits diverse environments.
- Compact design with 1 row and standard 2.54 mm pitch for PCB integration.
- Gold plating on contacts ensures corrosion resistance and signal integrity.
- Male contact gender with solder termination type for easy assembly.
Product Description
Preci-Dip 811-SS-005-30-003191 is a high-quality spring loaded connector designed for surface mounting on PCBs. It features 5 straight, shrouded contacts arranged in a single row with a precise 2.54 mm pitch, suitable for a variety of electronics and electrical applications.
The connector utilizes spring loaded contacts made from brass with gold plating to ensure low and stable electrical resistance even under vibrations or mechanical movement. This results in exceptional connection reliability and signal integrity, essential for industrial, laboratory, and commercial electronics.
The housing is constructed from fibreglass reinforced polyethylene terephthalate, providing durable insulation and mechanical strength. The design supports operation in a wide temperature range from -55°C up to 125°C, making it appropriate for harsh environments.
Reliable spring loaded electrical connection for dynamic and static applications. Gold-plated brass contacts for corrosion resistance and optimal conductivity. Compact single-row design with 2.54 mm pitch for standard PCB layouts.
Wide operating temperature range from -55°C to 125°C. Surface mount type allowing automated PCB assembly. Rated for 3.5A current and 150V voltage, suitable for various electronic circuits. Shrouded contact design enhances durability and protection against accidental shorts.
Termination via solder ensures secure and lasting electrical contacts.
This connector is ideal for use in industrial controls, telecommunications equipment, instrumentation, and other electronic systems requiring durable and reliable multipoint connections. It adheres to UL 94V-0 flammability standards to ensure safety and regulatory compliance.
Country of origin: Switzerland. Explore our extensive range of PCB connectors and spring loaded contacts at EnvMart for your next project or production needs.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3.5A, making it suitable for various electronic circuits.
The connector is rated for a maximum voltage of 150V, which is appropriate for many applications.
It features a standard pitch of 2.54 mm, allowing for easy integration into PCB layouts.
The housing is made from fibreglass reinforced polyethylene terephthalate, and the contacts are made from brass with gold plating.
It operates within a temperature range of -55°C to 125°C, suitable for diverse environments.
This model has a total of 5 contacts arranged in a single row.
It utilizes solder termination, ensuring secure and lasting electrical contacts during assembly.
This connector features a shrouded design, which enhances durability and protection against accidental shorts.
The contacts are male, which is standard for many PCB applications.
The country of origin for this connector is Switzerland.
It is suitable for industrial controls, telecommunications equipment, instrumentation, and other electronic systems requiring reliable multipoint connections.
This model is designed for surface mounting on PCBs, with a compact design that fits standard layouts.
