Preci-Dip 813 Series Straight Through Hole Spring Loaded Connector, 6 Contacts, 2.54 mm Pitch, 2 Row 813-S1-006-10-017101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 813-S1-006-10-017101 |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 813 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Features spring-loaded contacts for low resistance and high reliability.
- Mounts through hole with a straight orientation.
- Constructed with brass contacts and gold plating for optimal conductivity.
- Housing uses fibreglass reinforced polyethylene terephthalate for durability.
- Supports a current rating of 3.5 A and voltage up to 150 V.
- Operates within temperature range from -55°C to 125°C.
- Includes a 2-row contact configuration with a 2.54 mm pitch.
- Solder termination type with male contact gender.
Product Description
Preci-Dip 813-S1-006-10-017101 Spring Loaded Connector is designed for precision PCB header applications, featuring 6 spring-loaded contacts arranged in 2 rows with a 2.54 mm pitch. This shrouded connector ensures robust electrical connections with low and stable resistance, ideal for industrial, electronic component assembly, manufacturing, and testing applications.
The connector's contacts are made from brass with gold plating, ensuring excellent conductivity and corrosion resistance. The housing is crafted from fibreglass reinforced polyethylene terephthalate, providing mechanical strength and thermal stability suitable for operating temperatures from -55°C to 125°C.
It supports a current of 3.5 A and withstands voltages up to 150 V. The through-hole mount and straight orientation facilitate secure PCB installation, and the solder termination type supports reliable mechanical and electrical connection. Shrouded design adds protection to prevent accidental shorts and enhances connector durability.
This product is ideal for use in industrial electronics, laboratory equipment, telecommunications, and other sectors requiring dependable PCB connectors with modular spring-loaded contacts. The plug-and-play nature simplifies assembly processes and maintains stable multipoint electrical contacts even under vibration or movement.
Spring-loaded contacts provide low resistance and maximum reliability. Brass contact material with gold plating for superior conductivity. Fibreglass reinforced PET housing enhances durability and stability. Operating temperature range from -55°C to 125°C for versatile applications.
Through-hole mounting with solder termination for secure PCB assembly. Shrouded design adds mechanical protection and prevents shorts. 2 row, 6 contact configuration with precise 2.54 mm pitch spacing. Rated for 3.5 A current and 150 V voltage.
This connector is manufactured in Switzerland, reflecting high quality and manufacturing precision. It suits electronics assembly, industrial automation, and manufacturing test equipment requiring high-performance PCB connectors. Browse Preci-Dip spring-loaded connectors and related PCB headers on EnvMart for more professional-grade electronic components.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3.5 A.
This model is rated for a voltage of up to 150 V.
It operates within a temperature range from -55°C to 125°C.
The connector features 6 contacts arranged in a 2-row configuration.
The contact pitch is 2.54 mm.
The contacts are made from brass with gold plating, while the housing is constructed from fibreglass reinforced polyethylene terephthalate.
It features a solder termination type for secure connections.
This model is designed for through-hole mounting.
The connector has a straight orientation for installation.
This connector is shrouded, providing additional protection against accidental shorts.
It is manufactured in Switzerland, reflecting high quality and precision.
This connector is suitable for industrial electronics, laboratory equipment, telecommunications, and other sectors requiring reliable PCB connections.
