Preci-Dip 813 Series Spring Loaded Connector 24 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, Through Hole 813-S1-024-10-016101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 813-S1-024-10-016101 |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 813 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector features fibreglass reinforced polyethylene terephthalate housing for durability.
- Each brass contact is gold plated to ensure low, stable electrical resistance.
- Rated for 3.5 Ampere current and 150 Volt operation.
- Operates reliably between -55°C and 125°C temperature range.
- Includes 2.54 mm row pitch and straight orientation with solder termination.
- Spring-loaded modular design guarantees stable connections during vibration or movement.
- Compatible with complementary SMT DIL pad connectors for flexible PCB implementations.
- The connector housing is durable and insulated for safe operation.
Product Description
Preci-Dip 813-S1-024-10-016101 spring loaded connector is designed for high reliability and durability in PCB assembly. Featuring 24 male contacts arranged in two rows with 2.54 mm pitch, it supports through hole mounting ensuring stable mechanical connections.
The housing is made from fibreglass reinforced polyethylene terephthalate, providing robust insulation and mechanical strength. The brass contacts are gold plated to minimize electrical resistance and ensure consistent signal quality. This connector is rated for a current of 3.5A and voltage of 150V, operating across a wide temperature range from -55°C to 125°C.
The spring-loaded contact design enables low resistance electrical multipoint connections, maintaining stable performance even under vibration or movement. The 4 mm plastic body height and 1.4 mm plunger stroke length support precise and secure engagement. This connector is shrouded for protection and features straight orientation with solder-type terminations.
These connectors are widely used in industrial electronics, manufacturing, and instrumentation for reliable PCB interconnections. They provide an excellent alternative to conventional connection methods where vibration resistance and low contact resistance are critical.
The connector housing is durable and insulated for safe operation. Gold plated brass contacts ensure long-term reliability. Designed for through hole mounting compatible with standard PCB layouts. Spring-loaded design prevents micro-discontinuities even in vibrating environments.
Operating temperature from -55°C to 125°C suits a variety of industrial applications.
Set your projects up for success with the Preci-Dip 813 Series connectors, engineered for precision and stability in complex electronic assemblies. Explore more PCB connectors and electronic components at EnvMart to complement your industrial needs.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector is rated for a current of 3.5 Amperes.
It can handle a maximum voltage of 150 Volts.
The operating temperature range for this model is between -55°C and 125°C.
This connector features 24 male contacts arranged in two rows.
It supports through hole mounting for stable mechanical connections.
The housing is made from fibreglass reinforced polyethylene terephthalate.
The contact pitch in this model is 2.54 mm.
This connector is shrouded, providing additional protection.
It uses solder-type terminations for secure connections.
The spring-loaded design enables stable connections even under vibration or movement.
It is widely used in industrial electronics, manufacturing, and instrumentation for reliable PCB interconnections.
The contacts are made of brass and are gold plated to minimize electrical resistance.
