Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 8 Contacts, 2.54 mm Pitch, 1 Row 811-S1-008-10-017101

Preci-Dip 811-S1-008-10-017101 Spring Loaded Connector is a high-precision, straight through hole connector designed for printed circuit boards. It features 8 spring-loaded contacts arranged in a single row with a 2.54 mm pitch, facilitating secure electrical connections with excellent mechanical stability.

The connector's housing is constructed from fibreglass reinforced polyethylene terephthalate, providing exceptional durability and thermal resistance ranging from -55°C to 125°C. The brass contacts are gold plated to ensure reliable conductivity and minimize electrical resistance, which is critical in high-performance electronic applications.

Its shrouded design protects the contacts from mechanical damage and contamination, supporting longevity and reliability of connections. The through hole mount type ensures secure fixation on the PCB, suitable for environments subject to vibration or mechanical stress.

This product is well-suited for industrial, manufacturing, and electronic assembly sectors requiring stable multi-point electrical connections. It is an excellent alternative to traditional connection methods due to its spring-loaded contacts which maintain continuous contact pressure and reduce micro-discontinuities.

Spring loaded contacts provide consistent, low resistance connections. Gold plated brass contacts ensure superior conductivity and corrosion resistance. Fibreglass reinforced housing offers high mechanical strength and thermal stability.

Operating temperature range from -55°C to 125°C enables use in varied environments. Shrouded connector design protects contact integrity and reliability. Through hole mounting ensures robust PCB attachment. Compact 2.54 mm pitch and 1-row configuration for space-efficient PCB design.

Suitable for industrial electronics, power connectors, and PCB header applications.

The connector is manufactured in Switzerland maintaining stringent quality standards. This makes it an ideal choice for demanding applications such as industrial tools, laboratory equipment, and commercial electronics assemblies. Explore additional Preci-Dip connectors and electronic components on EnvMart for your next project.
