Preci-Dip 803 Series Right Angle PCB PCB Socket 4-Contact 2 Row 2.54 mm Pitch Solder 803-87-004-20-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | PCB |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Offers high current capacity of 12A for reliable performance.
- Features black glass filled polyester housing material for durability.
- Right angle orientation enables compact PCB mounting solutions.
- Constructed with beryllium copper alloy contacts with gold flash plating.
- Operates within temperature range from -55°C to 125°C.
- Connector system designed for board-to-board applications.
- Designed and manufactured in Switzerland ensuring quality standards.
- Supports voltage rating up to 150V allowing versatility in electronic circuits.
Product Description
Preci-Dip 803-87-004-20-001101 is a high-quality right angle PCB socket from the 803 Series designed for reliable electronic connectivity. This connector features 4 contacts arranged in 2 rows with a pitch of 2.54 mm, facilitating precise and space-efficient internal connections on printed circuit boards.
The socket housing is made from black glass filled polyester, offering exceptional mechanical strength and resistance to environmental factors. The contacts utilize a beryllium copper alloy with a gold flash plating for excellent conductivity and corrosion resistance, enhancing durability and signal integrity.
Operating ranges extend from a minimum temperature of -55°C up to a maximum of 125°C, making this socket suitable for various industrial and electronic applications where temperature extremes may be encountered. It supports a maximum current rating of 12 amperes and a voltage rating of 150 volts, accommodating medium-power electronic devices.
The right angle orientation and PCB mount type make this socket ideal for board-to-board connector systems, enabling compact and efficient circuit assemblies. The termination is via solder, ensuring a strong electrical and mechanical connection.
Manufactured in Switzerland, this component meets stringent quality standards even though specific approvals are not indicated. Its design supports through-hole and surface mount device (SMD) implementations for diverse manufacturing setups.
High current capacity of 12A for dependable electrical performance. Durable black glass filled polyester housing. Right angle PCB mount for optimized board layout. Beryllium copper alloy contacts with gold flash plating.
Wide operating temperature range from -55°C to 125°C. Board-to-board connector system for seamless electronic integration. Voltage rating up to 150V suitable for various circuits. Solder termination ensures firm mounting on PCB.
Ideal for industrial, electronic manufacturing, and assembly operations.
This Preci-Dip PCB Socket is a reliable choice for electronic designers and manufacturers aiming for high-quality board interconnections. Browse more products from the Preci-Dip series on EnvMart to find compatible connectors and accessories to complete your setup.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a maximum current capacity of 12 amperes, ensuring reliable electrical performance for medium-power applications.
The voltage rating is up to 150 volts, making it suitable for various electronic circuits.
The housing is made from black glass filled polyester, while the contacts are constructed from beryllium copper alloy with gold flash plating for enhanced conductivity.
It operates within a temperature range from -55°C to 125°C, accommodating a variety of industrial and electronic applications.
This socket features 4 contacts arranged in 2 rows, with a pitch of 2.54 mm for precise connections on printed circuit boards.
It utilizes solder termination, ensuring a strong electrical and mechanical connection to the PCB.
It has a right angle orientation, which facilitates compact PCB mounting solutions.
Yes, it is designed as a board-to-board connector system, ideal for seamless electronic integration.
This product is manufactured in Switzerland, adhering to stringent quality standards.
The pitch size of the contacts is 2.54 mm, which is standard for many PCB applications.
The contact gender for this socket is female, designed for compatibility with male connectors.
This socket is part of the Preci-Dip 803 Series, which includes various connectors for PCB applications.
