Panasonic PCB Signal Relay, 5V DC Coil, 2A Switching Current, DPDT Contact Configuration TQ2-L-5V
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 14mm |
| Model | TQ2-L-5V |
| Width | 9mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | TQ |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | Through Hole |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 250Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 125V ac |
| Coil Power | 100mW |
| Switching Power | 60W |
| Panasonic PCB Mount Latching Relay, 5V dc Coil, 1A Switching Current, 4PDTBrand | Panasonic |
Key Features
- Compact size of 14mm length, 9mm width, and 5mm height for high-density PCB mounting.
- Gold-plated contacts ensure high contact reliability and low electrical resistance.
- Operates efficiently within -40°C to 70°C temperature range.
- Switching voltage supports up to 125V AC and 220V DC, handling up to 60W switching power.
- Low coil power consumption of 100mW with coil resistance at 250Ω.
- Suitable for communications, office automation, measurement equipment, and industrial machine applications.
- Through-hole mounting enhances mechanical stability on PCBs.
- UL recognized and RoHS compliant, manufactured in Japan.
Product Description
Panasonic TQ2-L-5V PCB Signal Relay is a high-performance electronic component designed for efficient and reliable signal switching. Featuring a compact design with dimensions 14mm (L) x 9mm (W) x 5mm (H), this relay is perfect for applications requiring low-profile mounting and high-density installation on printed circuit boards.
This signal relay operates with a 5V DC coil and features a DPDT (Double Pole Double Throw) contact configuration capable of switching currents up to 2A. The gold-plated twin crossbar contacts ensure excellent conductivity and long-term durability with contact resistance as low as 50 milliohms. It supports switching voltages up to 125V AC and 220V DC, providing versatility across various electronic circuits.
Designed to withstand a broad operational temperature range from -40°C to 70°C, this relay is suitable for demanding environments including communications systems, office automation devices, measurement tools, and industrial machinery. Its low coil power of 100mW and coil resistance of 250 ohms make it energy efficient while maintaining fast and reliable switching performance.
The relay employs through-hole mounting technology for robust mechanical attachment, enhancing reliability in vibration-prone settings. Panasonic's TQ series latching technology provides stable relay operation with minimal power consumption, making it ideal for compact and energy-conscious designs.
Manufactured in Japan, this relay meets RoHS standards and is UL recognized, assuring compliance with international quality and safety requirements. Its high contact reliability and low thermal electromotive force contribute to consistent performance across its lifecycle.
Compact 5 mm height enables high-density PCB mounting. Gold-clad contacts deliver superior conductivity and durability. Supports switching power up to 60 watts. Latching coil power consumption ranges from 200 to 280 milliwatts depending on coil state.
Meets strict environmental and safety standards. Ideal for industrial, communication, and office automation applications.
This Panasonic PCB Signal Relay ensures dependable switching performance for sophisticated electronics designs. Explore more Panasonic components and PCB relays on EnvMart to fulfill your industrial and laboratory electronic needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a switching current capacity of 2A.
The relay has a compact size of 14mm in length, 9mm in width, and 5mm in height.
It operates with a coil voltage of 5V DC.
The relay supports switching voltages up to 125V AC and 220V DC.
This relay features a DPDT (Double Pole Double Throw) contact configuration.
The contact resistance is as low as 50 milliohms.
It operates efficiently within a temperature range of -40°C to 70°C.
The coil power consumption is 100mW with a coil resistance of 250Ω.
This model employs through-hole mounting for enhanced mechanical stability.
The contacts are made of gold-plated material to ensure high reliability and low electrical resistance.
Yes, it is RoHS compliant and UL recognized, ensuring it meets international quality and safety standards.
It is suitable for communications, office automation, measurement equipment, and industrial machine applications.
