HARTING D-Sub Standard Series Male Crimp D-Sub Connector Contact Gold over Nickel Signal 24 AWG 09670007167
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | HARTING |
| Current | 7.5A |
| Length | 14.48mm |
| Gender | Male |
| Contact Material | Brass |
| Series | D-Sub Standard |
| Termination Type | Crimp |
| Contact Type | Signal |
| Contact Plating | Gold over Nickel |
| Minimum Wire Size mm² | 0.09mm² |
| Maximum Wire Size mm² | 0.24mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 24AWG |
| Maximum Contact Resistance | 10mΩ |
Key Features
- This male crimp contact is compatible with wires sized from 28 AWG to 24 AWG.
- Constructed from durable brass material ensuring longevity and excellent electrical performance.
- Features gold plating over nickel on the contact surface for enhanced signal reliability.
- Rated for a maximum current of 7.5 amperes at low contact resistance of 10 milliohms.
- Contact length measures precisely 14.48 millimeters for standard D-Sub connector fitting.
- Termination is by crimping method for secure and efficient wire attachment.
- Manufactured to IEC 60 807 standards ensuring industrial quality and reliability.
- Made in Germany, guaranteeing premium European manufacturing quality.
Product Description
HARTING 09670007167 Male Crimp D-Sub Connector Contact belongs to the D-Sub Standard Series and is engineered for reliable signal transmission in electronic and industrial applications. Crafted with brass as the base material and gold over nickel plating on the contact surface, this component offers excellent conductivity and corrosion resistance.
The contact is designed for wires with cross-sectional areas ranging from 0.09 mm² up to 0.24 mm², corresponding to 28 AWG to 24 AWG wire sizes. It supports a maximum current rating of 7.5 A with minimal contact resistance of 10 milliohms, ensuring stable electrical connections in demanding environments.
Termination is achieved through crimping, providing a secure mechanical and electrical bond between the contact and the wire. The overall length of 14.48 mm complies with standard D-Sub specifications, facilitating compatibility with a wide range of Harting D-Sub connectors.
This contact is manufactured in Germany and adheres to IEC 60 807 standards, reflecting its quality and suitability for use in various industrial, electronic, and communications equipment assemblies.
Additional tooling such as manual crimp tools and insertion/extraction tools designed for Harting D-Sub contacts are recommended for optimal assembly efficiency and contact reliability.
This male crimp contact suits crimping onto wires sized 28 to 24 AWG. Brass construction ensures toughness and electrical performance. Gold over nickel plating enhances signal integrity and corrosion resistance. 7.5 A maximum current capacity supports moderate power applications.
Length of 14.48 mm fits standard D-Sub connector shells. Crimp termination provides secure and reliable wire connection. Manufactured under IEC 60 807 compliance at German facilities. Recommended crimp and insertion tools improve assembly efficiency.
Explore more Harting D-Sub connectors and related electronic components available at EnvMart for your electronic manufacturing and industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this male crimp D-Sub connector contact is 7.5 amperes.
This connector contact is compatible with wire sizes ranging from 28 AWG to 24 AWG, or cross-sectional areas from 0.09 mm² to 0.24 mm².
The contact is constructed from brass and features gold plating over nickel on the contact surface, enhancing conductivity and corrosion resistance.
The length of this male crimp contact is 14.48 millimeters, which complies with standard D-Sub specifications.
Termination for this connector contact is achieved through a crimping method, providing a secure mechanical and electrical bond with the wire.
This connector contact is manufactured in accordance with IEC 60 807 standards, ensuring industrial quality and reliability.
The maximum contact resistance for this connector contact is 10 milliohms.
This connector contact is manufactured in Germany, reflecting premium European manufacturing quality.
This male crimp contact is suitable for use in various electronic and industrial applications, particularly for reliable signal transmission.
Yes, it is recommended to use manual crimp tools and insertion/extraction tools designed for Harting D-Sub contacts for optimal assembly efficiency.
This connector contact is classified as a signal contact, designed specifically for signal transmission applications.
This connector contact belongs to the D-Sub Standard Series.
