Amphenol Communications Solutions Minitek Series Straight Through Hole PCB Header, 18 Contact, 2 mm Pitch, 2 98414-G06-18ULF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 200V |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 2A |
| Model | 98414-G06-18ULF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | Minitek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 18 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.5mm |
| Mating Pin Length | 4mm |
Key Features
- The header has 18 gold-plated contacts ensuring reliable electrical performance.
- Constructed with a thermoplastic housing for durability.
- It features 2 rows with a 2 mm row pitch for compact design.
- Supports a current rating of 2 amperes and voltage up to 200 volts.
- Mount type is through hole with vertical orientation suitable for PCB mounting.
- Contact material is copper alloy with gold plating to resist corrosion.
- Minimum operating temperature is -40°C and maximum is 125°C, ensuring stable operation in harsh environments.
- Termination type is solder with a contact tail pin length of 2.5 mm and mating pin length of 4 mm.
Product Description
Amphenol Communications Solutions presents the 98414-G06-18ULF PCB Header, part of the Minitek Series. This straight through hole connector features 18 male contacts arranged in 2 rows with a 2 mm pitch, designed specifically for board-to-board electrical connections. Its robust thermoplastic housing provides durability for demanding industrial and electronic applications.
The header is suitable for current up to 2A and voltage up to 200V, supporting reliable signal transmission. It offers a vertical orientation with through hole mount type ensuring secure soldering onto printed circuit boards. Contact pins are made of copper alloy with gold plating for enhanced corrosion resistance and longevity.
Operating temperature ranges from -40°C to 125°C, making it ideal for environments with temperature fluctuations. The tail pin length measures 2.5 mm while the mating pin extends 4 mm to guarantee proper mechanical engagement and electrical connectivity.
This product is manufactured in France and is well suited for use in electronics manufacturing, industrial automation, telecommunications equipment, and other precision electronic assemblies requiring high-quality PCB interconnect solutions.
The header has 18 gold-plated contacts ensuring reliable electrical performance. Constructed with a thermoplastic housing for durability. It features 2 rows with a 2 mm row pitch for compact design. Supports a current rating of 2 amperes and voltage up to 200 volts.
Mount type is through hole with vertical orientation suitable for PCB mounting. Contact material is copper alloy with gold plating to resist corrosion. Minimum operating temperature is -40°C and maximum is 125°C, ensuring stable operation in harsh environments.
Termination type is solder with a contact tail pin length of 2.5 mm and mating pin length of 4 mm. Explore the extensive range of PCB connectors and components at EnvMart to meet all your circuit board assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 2 amperes and a voltage rating of 200 volts.
The model features a 2 mm pitch and has 18 contacts arranged in 2 rows.
It is constructed with a thermoplastic housing and features contacts made of copper alloy with gold plating for corrosion resistance.
The operating temperature range is from -40°C to 125°C, allowing stable operation in harsh environments.
This model is designed for through hole mounting with a vertical orientation, ensuring secure soldering onto printed circuit boards.
The termination type for the contacts is solder, which is suitable for secure electrical connections.
The contact tail pin length is 2.5 mm, while the mating pin length is 4 mm, ensuring proper mechanical engagement.
This product is manufactured in France.
It utilizes a board-to-board connector system, designed for reliable electrical connections between PCBs.
Yes, it is well suited for use in electronics manufacturing, industrial automation, and telecommunications equipment.
The contact gender for this model is male, allowing for compatibility with female connectors.
The gold plating on the contacts enhances corrosion resistance and longevity, ensuring reliable electrical performance.
