Samtec IPL1 Series Straight Through Hole PCB Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1

Free Delivery in India | Lowest Global Shipping Charges

Samtec IPL1 Series Straight Through Hole PCB Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1

Name: Samtec IPL1 Series Straight Through Hole PCB Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1
Brand: Samtec
SKU: 99227
Price: 6.04 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	954V
Brand	Samtec
Orientation	Straight
Model	IPL1
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	IPL1
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	40
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.05mm

Key Features

Features a shrouded, straight orientation with through-hole mount style.
Manufactured with liquid crystal polymer housing for durability and heat resistance.
Phosphor bronze contacts plated with gold ensure excellent electrical conductivity.
Operates reliably between -55°C to 125°C temperature range.
Rated for voltage up to 954 V and current of 3.8 A at 95°C.
Tail pin length measures 3.05 mm for secure solder termination.
Suitable for industrial electronics, telecommunications, and PCB assembly.
Meets industry standards though no specific certifications listed.

Product Description

Samtec IPL1 Series Straight Through Hole PCB Header IPL1 is a precision wire-to-board connector designed with 40 male contacts spaced at a 2.54 mm pitch in a dual-row, straight configuration. Constructed with high-quality liquid crystal polymer housing and phosphor bronze contacts plated with gold, this shrouded header provides dependable electrical performance and mechanical strength for demanding industrial and electronic applications.

Its through-hole mounting style allows for robust board connections, ensuring durability in environments subject to mechanical stress or vibration. The product is rated for operation from -55°C to 125°C, making it suitable for a wide range of temperature conditions encountered in commercial and industrial equipment.

With a voltage rating of 954 V and a current rating of up to 3.8 amperes at 95°C, it supports highly reliable electrical connections for power and signal transmissions.

Applications include use in telecommunications equipment, industrial control systems, computing hardware, and other electronic assemblies requiring secure connections. The 3.05 mm tail pin length facilitates solid solder joins, enhancing mechanical retention and electrical conductivity.

Shrouded, 2-row, straight orientation with 2.54 mm pitch. Housing made from durable liquid crystal polymer. Male contact pins manufactured from phosphor bronze with gold plating. Operates within temperatures from -55°C to 125°C.

Voltage rating up to 954 V and current rating of 3.8 A @ 95°C. Through-hole mount type for secure PCB installation. Tail pin length of 3.05 mm for effective solder termination. Designed for industrial, electronic, and telecommunications applications.

This Samtec PCB Header series IPL1 offers high performance and reliability for demanding electronics manufacturing and assembly needs. It is a new product made in accordance with industry best practices for quality and durability.
