RS PRO 5A T Glass Cartridge Fuse, 5 x 20 mm, 250V AC, Time Lag, Glass Body 177-8088

RS PRO model 177-8088 is a 5A, T-speed rated glass cartridge fuse with a 5 x 20 mm size, designed for protection of electrical devices and internal circuits against overcurrent and short circuit conditions at 250V AC.

The fuse possesses a glass body material, which enables quick visual confirmation to identify whether the fuse has operated by blowing, making maintenance more straightforward.

It features a time lag (also called T-speed) characteristic that tolerates short-term surges or inrush currents without immediate blowing, providing extra protection for equipment with transient current peaks.

With a maximum operating temperature of 125°C and a minimum operating temperature of -55°C, this fuse is reliable across a wide range of environments and installations.

The breaking capacity is classified as Low Breaking Capacity (LBC), appropriate for controlling fault currents without hazardous ruptures or explosions, making it a safe option for many electrical applications.

This cartridge fuse complies with major standards and approvals including CSA, UL, RoHS, PSE GTE, and KTL, ensuring it meets stringent quality and safety requirements. Provides protection from short circuits and overcurrent faults in electrical circuits.

5 x 20 mm standard cartridge size suitable for many fuse holders. Time lag (T) fuse characteristic allows tolerance of short current surges without blowing. Glass body allows visual inspection to determine if the fuse has blown.

Maximum operating temperature of 125°C ensures reliability in harsh environments. Low breaking capacity suitable for typical industrial and residential applications. Complies with standards CSA, UL, RoHS, PSE GTE, and KTL.

Ideal for use in industrial, commercial, automotive, and residential electrical protection.

This fuse is widely used across industrial, commercial, automotive, home and residential electrical systems, protecting motors, air-conditioning units, refrigerators, and pumps among other equipment. Its durable glass body, reliable time lag characteristic, and standard cartridge size make it compatible with most fuse holders and ideal for cost-effective circuit protection.
