Schurter 32A Time Delay Ceramic Cartridge Fuse, 6.3 x 32 mm, 400/500V AC, SHT Series 8020.5026.G
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 500, 400V ac |
| Diameter | 6.3mm |
| Brand | Schurter |
| Body Material | Ceramic |
| Model | 8020.5026.G |
| Overall Length | 32mm |
| Current Rating | 32A |
| Series | SHT |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Fuse Characteristics | Time Delay |
| Fuse Size | 6.3 x 32 mm |
| UL File Number | E41599 listed |
Key Features
- Rated for 32A current carrying capacity.
- Operates at AC voltages of 400 and 500 volts.
- Cylindrical ceramic body offers high durability and heat resistance.
- Time-Lag T slow blow fuse characteristic for pulse-shaped continuous currents.
- Wide operating temperature range from -40°C to 85°C.
- Nickel-plated copper alloy endcaps and tin-plated copper axial leads ensure reliable conductivity.
- Breaking capacity of 1500A AC and 1000A DC for safety under fault conditions.
- Suitable for 3-phase, DC systems, frequency converters, photovoltaic, and power electronics applications.
Product Description
Schurter 8020.5026.G is a ceramic cartridge fuse with a 32 ampere time delay rating, designed to provide reliable electrical circuit protection in industrial and commercial applications. This fuse features a 6.3 x 32 mm cylindrical ceramic body which allows for excellent heat dissipation and electrical insulation. Its design targets both AC and DC circuits with maximum voltage ratings of 400 and 500 volts.
The fuse belongs to the SHT series with time delay characteristics, allowing it to tolerate transient pulses, making it well-suited for frequency converters, photovoltaic panels, and power electronics where momentary surges occur. The fuse's ambient operating temperature range of -40°C to 85°C ensures dependable performance in varying climates and environments.
The construction includes nickel-plated copper alloy endcaps on both ends and tin-plated copper axial leads, which provide robust mechanical and electrical connections for installation. It offers a breaking capacity of 1500 amps at AC and 1000 amps at DC, ensuring safe interruption of short circuit currents.
Rated current of 32A ensures suitability for moderate power circuits requiring protection. Ceramic body provides high-temperature tolerance and mechanical strength. Time-lag T slow blow characteristic supports applications with transient current spikes.
Compliance with RoHS standards and certifications from UL and CSA provide assurance of quality and safety. Applications include three-phase systems, DC electrical circuits, frequency converters, photovoltaic systems, and power electronics.
This Schurter Cartridge Fuse is made in China and is designed for industrial, commercial, and laboratory electrical protection use. It offers dependable and long-lasting fuse performance for a variety of electrical systems.
Explore more Schurter fuses and related electrical protection components on EnvMart to meet diverse engineering and maintenance requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The fuse has a current rating of 32A, making it suitable for moderate power circuits requiring protection.
It operates at AC voltages of 400V and 500V, ensuring compatibility with various electrical systems.
The fuse has a size of 6.3 x 32 mm, which is standard for many cartridge fuse applications.
It has a breaking capacity of 1500A AC and 1000A DC, providing safety under fault conditions.
The operating temperature range is from -40°C to 85°C, allowing it to function in various environmental conditions.
The fuse features a cylindrical ceramic body, nickel-plated copper alloy endcaps, and tin-plated copper axial leads for reliable conductivity.
It has a time-lag T slow blow characteristic, which allows it to handle transient current spikes effectively.
Yes, it complies with RoHS standards and is certified by UL, ensuring quality and safety.
This fuse is suitable for three-phase systems, DC electrical circuits, frequency converters, photovoltaic systems, and power electronics.
This fuse is manufactured in China, as indicated by its country of origin.
The model number of this fuse is 8020.5026.G, which is part of the SHT series.
The diameter of the fuse is 6.3 mm, which is consistent with its cartridge design.
