Hongfa Europe GMBH PCB Power Relay 24V dc Coil, 20A Switching Current, SPST HF115F-L/24-H3L1TF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.7mm |
| Length | 29mm |
| Model | HF115F-L/24-H3L1TF |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF115F-L |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 20A |
| Terminal type | PCB Terminal |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1440Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 300V dc |
| Switching AC Voltage | 440V ac |
| Coil Power | 400mW |
Key Features
- Supports power switching up to 4KVA in AC applications.
- Operates reliably in temperature ranges from -40°C to 85°C.
- Has a coil resistance of 1440 Ω and coil power of 400 mW.
- Equipped with silver alloy contacts offering low contact resistance of 100 mΩ.
- Maintains isolation voltage of 5KVAC between coil and contact.
- Durable for up to 2 million operational cycles.
- Compliant with RoHS standards ensuring environmental safety.
- Ideal for industrial machinery, automotive engines, medical equipment, and telecommunication devices.
Product Description
Hongfa Europe GMBH HF115F-L/24-H3L1TF PCB Power Relay is engineered for reliable power switching using a 24V DC coil and single pole single throw (SPST) contact configuration supporting 20A switching current. It features silver alloy contacts and PCB mounting for easy integration in electronic assemblies.
This relay offers switching voltages up to 440V AC and 300V DC, supporting power up to 4KVA. Its compact form factor includes dimensions of 29mm length, 15.7mm height, and 12.7mm width, making it suitable for space-constrained designs.
Designed to operate efficiently between -40°C and 85°C, it withstands up to 2 million switching cycles, ensuring long-term durability in demanding environments. The relay benefits from a 5KVAC isolation voltage between coil and contact, enhancing safety in industrial applications.
Coil resistance is rated at 1440 Ω with a coil power consumption of 400 milliwatts. The contact resistance is low, at 100 milliohms, for minimal power loss.
Environmental compliance is assured with RoHS certification. Applications span automotive engines, household appliances, industrial machinery, medical equipment, and telecommunication systems. This relay supports reliable control in a wide array of electronic and industrial equipment.
Supports power switching up to 4KVA in AC applications. Operates reliably in temperature ranges from -40°C to 85°C. Has a coil resistance of 1440 Ω and coil power of 400 mW. Equipped with silver alloy contacts offering low contact resistance of 100 mΩ.
Maintains isolation voltage of 5KVAC between coil and contact. Compact PCB mount design with dimensions: 29mm length, 15.7mm height, and 12.7mm width. Durable for up to 2 million operational cycles. Compliant with RoHS standards ensuring environmental safety.
Ideal for industrial, automotive, medical, and telecom applications. Explore more reliable Power Relays and electronic components in the Relays & Contactors category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a switching current of 20A.
It has dimensions of 29mm in length, 15.7mm in height, and 12.7mm in width.
The coil voltage for this unit is 24V DC.
This relay features a single pole single throw (SPST) contact configuration.
It supports a maximum switching voltage of 440V AC.
The minimum operating temperature is -40°C.
It is equipped with silver alloy contacts, which provide low contact resistance of 100 mΩ.
It maintains an isolation voltage of 5KVAC between the coil and contact.
The coil resistance is rated at 1440 Ω.
This relay is durable for up to 2 million operational cycles.
The maximum operating temperature is 85°C.
Yes, it is compliant with RoHS standards, ensuring environmental safety.
