KEMET A72 Film Capacitor 10 nF ±10 % 1500 V dc 450 V ac Through Hole A72SQ2100AA00K

KEMET A72SQ2100AA00K Film Capacitor is a high-performance capacitor featuring a capacitance of 10 nF with ±10 % tolerance. It is rated to operate at 1500 V dc and 450 V ac, suited for Through Hole mounting configurations. This capacitor is constructed using polypropylene or metallized film combined with metal foil, providing reliable electrical characteristics and durability for advanced electronic applications.

The capacitor is encapsulated in a durable polyester tape wrapping case fortified with thermosetting resin, designed to protect the internal winding and maintain stability over various operating conditions. The axial leads are 40 mm long with a diameter of 0.8 mm, welded precisely for consistent electrical contact.

This component is designed to operate reliably in temperatures ranging from -55°C to 105°C. It conforms to UL and IEC 60384-13 standards, ensuring compliance with international safety and quality norms. The capacitor offers a low dissipation factor of 0.1%, optimizing circuit efficiency and reducing energy losses.

The package employs a plastic case with axial lead terminals, featuring lead-free terminations and self-healing capabilities that enhance its life span and reliability. Dimensionally, the capacitor measures 28 mm in length and 9.5 mm in width, with diameters varying from 5 to 22.5 mm to accommodate different circuit layouts.

This KEMET capacitor series covers capacitance ranges from 47 pF up to 0.33 μF and voltage ratings from 100 to 2000 V dc. The A72 series is widely used across industrial electronics, manufacturing equipment, laboratory instrumentation, and other high-frequency electrical applications.

Constructed of polypropylene or metallized film with metal foil for stable performance. Encapsulated with polyester tape and thermosetting resin protection. Axial leads of 40 mm length and 0.8 mm diameter for secure mounting.

Wide operating temperature range from -55°C to 105°C. Compliance with UL and IEC 60384-13 standards. Dissipation factor of 0.1% ensures energy-efficient operation. Plastic case and lead-free terminations support environmental safety.

Self-healing properties enhance durability and reliability. Dimensions of 28 mm length and 9.5 mm width with diameter 5 - 22.5 mm. This capacitor is ideal for use in electronic assemblies, PCB designs, industrial machinery control, and telecommunications equipment.
