Cosel DC/DC Converter 12V dc, -12 V dc 250 mA, 24V dc Input, 18V Input, 6 W, PCB Mount, SIP-8 Package MGW62412
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGW DC/DC Converter, 12V dc, -12 V dc/ 250 m |
| Brand | Cosel |
| Efficiency | 88% |
| Length | 22mm |
| Model | MGW62412 |
| Depth | 12mm |
| Gross Weight | 7g |
| Width | 9.5mm |
| Mount Type | PCB |
| Series | MGW |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-8 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 200mV Pk-Pk |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 24V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 7 |
| Output Voltage 1 | 12, -12V dc |
| Output Current 1 | 250mA |
| Output Voltage Adjustment Range | 11.64 to 12.36 V |
| Isolation Voltage | 1kV dc |
| Output Current 2 | 0.2A |
| Output Voltage 2 | 15V |
Key Features
- Converts 18V to 24V DC input to stable 12V and -12V output voltages.
- Provides 6 watts maximum output power in SIP-8 package type.
- Equipped with integrated overcurrent protection for safety.
- Supports operation in temperature range from -40°C to 85°C.
- Features low ripple and noise of 200mV peak-to-peak for clean power supply.
- Offers isolation voltage rating of 1kV DC for enhanced safety.
- Efficiency rated at 88% for energy-saving performance.
- Contains 7 pins for PCB mount integration.
Product Description
Cosel MGW62412 is a precision DC/DC Converter designed for stable dual voltage outputs of 12V and -12V at 250 mA current. It accepts a DC input voltage range between 18V and 24V, making it highly versatile for electronic power supply applications. This device is intended for PCB mounting and packaged in a SIP-8 format, supporting compact and space-efficient circuit board designs.
The converter features an output voltage adjustment range of 11.64 to 12.36 V and maintains low ripple and noise of 200mV peak-to-peak, ensuring a clean and stable output power suitable for sensitive electronic components. It provides high isolation voltage of 1kV DC to safeguard against voltage spikes and interference.
Operational in extreme temperature conditions from -40°C to 85°C, the MGW62412 is reliable in industrial, telecommunications, and instrumentation environments. The device integrates overcurrent protection to enhance operational safety and longevity.
Physically, it is a compact module measuring 22 mm in length, 12 mm in depth, and 9.5 mm in width, with a lightweight of 7 grams - ideal for embedded power supply solutions on PCBs. Efficiency performance of 88% minimizes energy losses, contributing to environmentally conscious designs.
Cosel MGW62412 complies with multiple global standards including UL62368-1, EN 62368-1, CE, RoHS, and others, ensuring adherence to safety and quality benchmarks. Its robust build and certification make it suitable for use in industrial electronics, laboratory equipment, automated systems, and other commercial electrical applications.
Converts 18V to 24V DC input to dual stable 12V DC outputs. 6W output power in compact SIP-8 package for PCB mounting. Low ripple and noise ensures clean power for sensitive electronics. Supports wide temperature range for industrial and commercial use.
High isolation voltage of 1kV DC enhances operational safety. Overcurrent protection guards against electrical faults. Meets UL, CE, RoHS, and other international safety standards. Lightweight and compact dimensions suitable for space-constrained environments.
High efficiency at 88% reduces power losses and heat generation. Explore the comprehensive offerings in DC/DC converters at EnvMart for reliable industrial and electronic components tailored to your application needs.
Explore more products in our DC-DC Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is between 18V and 24V DC.
This unit provides dual output voltages of 12V and -12V DC.
The maximum output power of this converter is 6 watts.
It can output a maximum current of 250 mA.
The efficiency rating of this converter is 88%.
It operates within a temperature range of -40°C to 85°C.
The isolation voltage rating is 1kV DC, enhancing operational safety.
This model measures 22 mm in length, 12 mm in depth, and 9.5 mm in width.
It has 7 pins for PCB mounting integration.
The ripple and noise is rated at 200mV peak-to-peak.
It complies with UL62368-1, EN 62368-1, CE, and RoHS standards.
This model is suitable for industrial electronics, laboratory equipment, and automated systems.
