Weidmüller TRZ Series Interface Relay, DIN Rail Mount, 230V Coil, DPDT Contact Configuration, 8A Switching 1123700000
Specifications
| Country of Origin | China |
|---|---|
| Brand | Weidmüller |
| Height | 88mm |
| Length | 90mm |
| Width | 12.8mm |
| Mount Type | DIN Rail |
| Contact Material | Silver Alloy |
| Series | TRZ |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 8A |
| Terminal type | Spring Clamp |
| Coil Voltage | 230V |
| Coil Current | 45mA |
| Switching DC Voltage | 250V dc |
| Switching AC Voltage | 250V ac |
| Optionally with multiple-voltage input | 24...230 V UC |
Key Features
- Coil voltage of 230V ensures compatibility with standard AC power supplies.
- Double-pole double-throw (DPDT) contact configuration for versatile switching operations.
- Maximum switching current rated at 8A for reliable performance.
- Uses silver alloy contacts for enhanced conductivity and durability.
- Compact dimensions with a height of 88mm, width of 12.8mm, and length of 90mm.
- Spring clamp terminal type allows secure and easy connections.
- Coil current is 45mA, maintaining energy efficiency.
- Operating temperature range from -40°C to 60°C for robust industrial use.
Product Description
Weidmüller 1123700000 TRZ Series Interface Relay is a high-quality electromechanical relay designed for DIN Rail mount installation. It operates with a 230V coil voltage and features a double-pole double-throw (DPDT) contact configuration, providing flexible switching capabilities suitable for complex control systems.
The relay supports a maximum switching current of 8A and can switch AC voltages up to 250V and DC voltages up to 250V, making it suitable for various industrial and automation applications. Its silver alloy contacts ensure high conductivity and durability, enhancing long-term reliability.
This device uses spring clamp terminals, simplifying electrical connections and maintenance while ensuring secure attachment. The relay coil draws 45mA current, balancing efficiency and performance. With compact dimensions of 88mm height, 12.8mm width, and 90mm length, it fits easily within DIN rail assemblies.
Engineered to operate under harsh conditions, it supports temperatures from -40°C to 60°C. The relay complies with stringent standards such as EN 61000-6-4, EN 61000-6-2, EN 61000-6-1, and EN 55011, ensuring electromagnetic compatibility and interference immunity.
Additional features include optional multiple-voltage input ranges of 24 to 230 V UC and various protective input circuits like free-wheel diodes and RC elements. Its illuminated ejection lever facilitates quick and safe replacement in control panels.
This interface relay is widely used in industrial automation, electrical control panels, manufacturing equipment, and HVAC systems for signal isolation and control tasks. Coil voltage: 230V AC with efficient 45mA coil current.
Contact configuration: DPDT with 8A maximum switching current. Compact DIN Rail mount construction measuring 88mm by 12.8mm by 90mm. Durable silver alloy contacts for reliable electrical performance. Wide operating temperature range from -40°C to 60°C.
Spring clamp terminals for secure and quick wiring connections. Compliant with EN 61000-6-4, EN 61000-6-2, EN 61000-6-1 and EN 55011 electromagnetic compatibility standards. Features input protective circuits and illuminated ejection lever for enhanced usability.
Choose Weidmüller TRZ Series Interface Relay for reliable, compact, and standards-compliant relay solutions in industrial and automation applications. Browse EnvMart for more relays and electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 230V, ensuring compatibility with standard AC power supplies.
It supports a maximum switching current of 8A, suitable for reliable performance in various applications.
This model features a double-pole double-throw (DPDT) contact configuration, allowing versatile switching operations.
The relay has compact dimensions of 88mm in height, 12.8mm in width, and 90mm in length, making it suitable for DIN rail installations.
The coil current is 45mA, which helps maintain energy efficiency during operation.
It operates effectively within a temperature range of -40°C to 60°C, suitable for robust industrial use.
This interface relay uses spring clamp terminals, allowing for secure and easy electrical connections.
The contacts are made of silver alloy, which enhances conductivity and durability.
Yes, it complies with electromagnetic compatibility standards such as EN 61000-6-4, EN 61000-6-2, EN 61000-6-1, and EN 55011.
It can switch AC voltages up to 250V and DC voltages up to 250V, making it versatile for different applications.
This relay is designed for DIN rail mounting, facilitating easy installation in control panels and electrical systems.
It includes an illuminated ejection lever for quick and safe replacement, as well as optional multiple-voltage input ranges from 24 to 230 V UC.
