LEMO Circular Connector, 14 Contacts, Panel Mount, M12 Connector, Socket, Female, IP68, Brass Housing EGG.1T.314.CLL

LEMO EGG.1T.314.CLL is a high-quality circular connector from the 314 Series, specifically designed for industrial and outdoor applications requiring reliable multipole connections. This model features 14 bronze contacts configured in a panel mount M12 socket with female contact gender, ensuring dependable electrical interfacing for sensitive and robust equipment.

The connector supports a current of 2A and voltages ranging between 30 and 42V, suitable for various low-voltage industrial instrumentation and automation systems. Its brass housing offers mechanical resilience and corrosion resistance, complemented by nickel-plated contacts for enhanced conductivity and durability.

The EGG.1T.314.CLL employs a Push-Pull self-latching system combined with a mechanical keying mechanism to prevent cross-mating, delivering secure and foolproof connection setups. The connector is IP68 rated according to IEC 60529 standards, guaranteeing high resistance to dust and water ingress, essential for harsh environmental conditions.

Operating across a wide temperature range from -55°C to 200°C, this model is well-suited for applications in aerospace, defense, land vehicles, electronic test equipment, and other industrial sectors demanding rugged connectors.

The connector’s mounting type is panel mount with a shell size of 16 mm and a straight orientation. It terminates by solder, providing stable contact integrity. The compact design and full 360° EMC shielding maintain signal quality and minimize interference, critical in sensitive electronics and communications systems.

14 contacts for multipole electrical connections. Panel mount type designed for fixed installation applications. Push-Pull self-latching system for easy and secure mating. IP68 rated for water and dust protection. Brass housing with nickel plated bronze contacts.

Solder termination method for reliable contact. Wide operating temperature range: -55°C to 200°C. Compatible with existing B series sockets. Mechanical key prevents incorrect mating. Shell size 16 mm with straight orientation.

This LEMO circular connector is ideal for industrial, laboratory, construction, and electronic instrumentation applications requiring a durable, reliable electrical interface with robust environmental protection. Explore more from the Industrial Circular Connectors category at EnvMart for comprehensive connector solutions.
