HARTING SV TSDC 15 Way Straight Panel Mount D-Sub Connector with Flange Female 1.0kV 7.5A 09670154715
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 1.0kV |
| Brand | HARTING |
| Orientation | Straight |
| Current | 7.5A |
| Mount Type | Panel Mount |
| Housing Material | Fibreglass Reinforced Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SV TSDC |
| Mounting Hardware | Flange |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | UL Recognised, UL 94-V0, RoHS |
| Contact Plating | Gold Plated |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | D-Sub |
Key Features
- Features a sturdy flange mount for secure panel installation.
- Utilizes gold-plated copper alloy contacts ensuring excellent conductivity and corrosion resistance.
- Supports a maximum current of 7.5 amperes and voltage rating up to 1.0 kilovolt.
- Constructed with fibreglass reinforced thermoplastic housing for durability and thermal stability.
- Operates reliably in temperatures ranging from -55°C to 125°C.
- Termination is performed via solder cup, providing solid connections.
- Complies with UL Recognised, UL 94-V0, and RoHS standards for safety and environmental requirements.
- Made in Germany, ensuring high manufacturing quality and precision.
Product Description
HARTING 09670154715 SV TSDC 15 Way Straight Panel Mount D-Sub Connector is engineered for industrial, electronic, and manufacturing environments requiring reliable and high-performance connector solutions. This female connector is outfitted with a robust flange mounting system for secure and stable panel installation, making it suitable for control panels, instrumentation, and communication equipment.
Built with gold-plated copper alloy contacts, this connector assures low electrical resistance and superior corrosion resistance, essential for demanding electrical applications. The housing material is fibreglass reinforced thermoplastic, providing excellent mechanical strength and resistance to thermal and chemical stress, enhancing the connector’s operational longevity.
The connector supports a current rating of 7.5 amperes and a voltage rating of 1.0 kV, suitable for mid-power electronic circuits and industrial control systems. It maintains reliable performance over an operating temperature range from -55°C to 125°C, allowing usage in harsh environments and varying climates.
Designed with solder cup termination and turned contacts, the connector allows straightforward and secure wire connections with excellent contact integrity. With industry certifications including UL Recognised, UL 94-V0, and RoHS compliance, it meets essential safety and environmental standards.
This model is produced in Germany, ensuring adherence to strict quality and manufacturing standards. The SV TSDC series includes variants with 15, 25, and 37 contacts; the 15-contact configuration provides an optimal balance between compactness and connectivity options.
Sturdy flange mounting provides secure panel attachment. Gold-plated copper alloy contacts ensure superior conductivity. Fibreglass reinforced thermoplastic housing offers durability. Operates within -55°C to 125°C temperature range.
Solder cup termination allows reliable wiring connections. Rated for 7.5A current and 1.0kV voltage. UL Recognised, UL 94-V0 flame retardant, and RoHS compliant. Manufactured in Germany to high-quality standards. Compact 15-contact configuration for versatile use.
This connector is ideal for integration in industrial controls, automation equipment, electronic instrumentation, telecommunications, and manufacturing applications requiring robust and compliant D-Sub interfaces. Explore the HARTING range on EnvMart for complementary connector solutions and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a voltage rating of 1.0 kilovolt (1.0kV).
It supports a maximum current of 7.5 amperes.
The housing is constructed from fibreglass reinforced thermoplastic, providing durability and thermal stability.
This model utilizes solder cup termination for secure wire connections.
It operates reliably within a temperature range of -55°C to 125°C.
This D-Sub connector features 15 contacts.
Yes, it is UL Recognised, UL 94-V0 compliant, and RoHS compliant.
It features a flange mount for secure panel installation.
The contacts are made from gold-plated copper alloy, ensuring excellent conductivity and corrosion resistance.
This model is manufactured in Germany, ensuring high manufacturing quality.
It belongs to the SV TSDC series of connectors.
It is suitable for use in industrial controls, automation equipment, electronic instrumentation, telecommunications, and manufacturing applications.
