Amphenol Communications Solutions Minitek Series Straight Surface PCB Socket 5-Contact 1 Row 2 mm Pitch 10131935-105ULF

Amphenol Communications Solutions 10131935-105ULF Minitek Series Straight Surface PCB Socket is a precision 5-contact, single row receptacle connector featuring a 2.00 mm pitch designed for board-to-board interconnection. It supports a current rating of 12A and a voltage rating of 200V, making it ideal for robust industrial, automotive, communications, and electronics applications.

The socket's glass filled housing material provides excellent mechanical strength and dielectric properties. The housing is constructed from UL94V-0 high-temperature thermoplastic, enabling the connector to withstand reflow soldering processes without degrading performance.

Contacts are female, made of copper with gold plating to ensure excellent conductivity and corrosion resistance. The dual beam contact design enhances electrical reliability under vibration and thermal cycling. The single row vertical PCB socket features a double solder tail on each pitch facilitating automatic assembly and ensuring consistent solder joint quality.

Operating temperatures range from -55°C to 125°C, supporting demanding environments. The compact 2.00 mm pitch minimizes board space usage, achieving around 38% space saving compared to traditional 2.54 mm systems, facilitating high-density PCB designs.

This Minitek Series connector is fully compatible within the modular Minitek 2.00 mm system and mates with Minitek PCB headers, providing flexible configuration options. It is well suited for board-to-board connections in automotive electronics, Industrial I/O modules, server drives, and programmable logic controllers (PLCs).

Compact 2.00 mm pitch reduces PCB space requirements significantly. 12A current rating suitable for multi-contact power delivery. Robust housing materials comply with UL94V-0 standards ensuring high heat resistance. Gold plated copper contacts with dual beam design for superior electrical performance.

Double solder tails optimize automated assembly processes. Wide operating temperature range supports harsh industrial environments. Compatible with the Minitek modular connector system ecosystem. Explore the extensive range of Amphenol Communications Solutions PCB Sockets and connectors on EnvMart to fulfill your technical and industrial component requirements.
