Molex Square Omni-Directional GPS Antenna, 1558 - 1610MHz, Adhesive Mount, UFL/IPEX MHF Connector, 0.9dBi Gain 206560-0300
Specifications
| Country of Origin | China |
|---|---|
| Brand | Molex |
| Connector Type | UFL/IPEX MHF |
| Bandwidth | 1610MHz |
| Series | 206560 |
| Gain | 0.9dBi |
| Lead Length | 0.3m |
| Standards/Approvals | EU RoHS China RoHS Compliant, EU ELV Not Relevant, REACH SVHC Not Contained |
| Maximum Frequency | 1610MHz |
| Connector Gender | Female |
| Minimum Frequency | 1558MHz |
| Internal/External | Internal |
| RF Protocols | GPS |
| Antenna Physical Form | Square |
| Antenna Mount Type | Adhesive |
| Directivity | Omni-Directional |
| Number of Bands | 3 |
Key Features
- Square omni-directional GNSS antenna covering 1558 to 1610MHz.
- Features adhesive mounting for secure and flexible installation.
- Equipped with UFL/IPEX MHF female connector and a 0.3-meter lead length.
- Internal antenna configuration with linear polarization.
- Offers 0.9dBi gain and supports multiple bands for diverse satellite tracking.
- RoHS compliant and suitable for industrial and electronic assembly.
- Ideal for embedded systems, asset tracking, and IoT devices.
- Robust square form factor ensures compact integration.
Product Description
The Molex 206560-0300 Square Omni-Directional GPS Antenna is engineered for superior performance in GNSS applications, supporting GPS, BeiDou, and GLONASS frequency bands from 1558MHz to 1610MHz. Designed with a square, compact form factor, this internal antenna integrates seamlessly into electronic assemblies and industrial devices, making it ideal for embedded systems and IoT hardware where reliability and minimal footprint are critical.
This antenna features an adhesive mount, allowing secure installation onto various surfaces while maintaining optimal signal acquisition. The integrated UFL/IPEX MHF female connector and 0.3-meter lead length offer versatile connectivity, supporting fast and easy assembly into custom PCBs or equipment housings.
Square-shaped omni-directional GNSS antenna covers a wide frequency range (1558 - 1610MHz). Delivers 0.9dBi gain, ensuring clear and consistent reception from multiple satellite systems. Equipped with a 0.3m lead and UFL/IPEX MHF female connector for flexible installation.
Engineered for internal use, with adhesive mounting for device integration. Designed for low-profile applications where performance and reliability are required. Compliant with EU RoHS, China RoHS, and REACH SVHC standards for global industrial compatibility.
Supports three bands for advanced GNSS reception (GPS, GLONASS, BeiDou). Ideal for embedded GNSS modules, asset and vehicle tracking, fleet management, smart metering, remote sensing, and industrial automation systems.
This product is part of Molex's 206560 series and is manufactured to provide reliable performance in challenging electronic and industrial environments. Its robust square design allows it to be easily installed in tight spaces within products like tracking devices, telemetry modules, and other compact electronics requiring precise global positioning signals.
Explore more GPS and RF antenna solutions from Molex or browse other industrial connectors and components in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a frequency range of 1558MHz to 1610MHz, supporting multiple GNSS systems including GPS, BeiDou, and GLONASS.
It has a gain of 0.9dBi, which helps in achieving clear and consistent reception from satellite systems.
It features an adhesive mount type, enabling secure installation on various surfaces.
This model is designed for internal use, making it suitable for integration into compact electronic devices.
It is compliant with EU RoHS, China RoHS, and REACH SVHC standards, ensuring compatibility for global industrial applications.
The antenna has a square physical form factor, which aids in compact integration into electronic assemblies.
This model supports three bands for enhanced GNSS reception, including GPS, GLONASS, and BeiDou.
It is ideal for embedded systems, asset tracking, fleet management, smart metering, and industrial automation systems.
The antenna features omni-directional directivity, allowing it to receive signals from multiple directions.
This GPS antenna is part of the Molex 206560 series, designed for reliable performance in various electronic applications.
