Amphenol Communications Solutions Quickie Series Straight Through Hole PCB Header, 10 Contacts, 2.54 mm Pitch, 2 75869-101LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 3A |
| Model | 75869-101LF |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Thermoplastic Polyester |
| Contact Material | Phosphor Bronze |
| Series | Quickie |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| No polarization | 75869-130LF, 75869-131LF and 75869-132LF |
| Right polarization | 75869-101LF and 75869-102LF |
| Right and Left polarization | 75869-103LF, 75869-104LF and 75869-105LF |
Key Features
- Provides reliable wire-to-board connectivity for PCB designs.
- Features a robust glass filled thermoplastic polyester housing for durability.
- Gold plated phosphor bronze contacts ensure high conductivity and resistance to corrosion.
- Supports a 3A current and up to 500V voltage rating for industrial applications.
- Through hole design enables secure soldering and mechanical strength.
- Shrouded configuration enhances connector alignment and prevents mis-mating.
- Polarization options for secure mating, right polarization as per model specification.
Product Description
Amphenol Communications Solutions 75869-101LF is a Quickie Series straight through hole PCB header designed for high-reliability wire-to-board connections in electronic assemblies. The header offers 10 male contacts arranged in 2 rows, with a 2.54 mm pitch, suitable for standard PCB layouts.
Its glass filled thermoplastic polyester housing provides excellent mechanical durability and thermal stability, withstanding operating temperatures from -65°C to 105°C. The connector employs phosphor bronze contacts plated with gold to maximize conductivity and minimize contact resistance over time, making it ideal for applications requiring dependable signal and power transmission.
The through hole mount design strengthens solder joints and resists mechanical stresses during assembly and operation. Shrouded body improves connector alignment, ensures polarization, and prevents accidental mis-mating. Right polarization is provided on this model, facilitating correct mating orientation with compatible Quickie Series receptacles.
Rated for 3A current and 500V, the header performs reliably in demanding industrial, instrumentation, and commercial electronic systems. Its solder termination allows secure installation on a wide range of PCB thicknesses.
The Quickie Series is compatible with Amphenol FCI IDC Quickie Receptacles and other interconnection systems. Applications include control panels, industrial automation, instrumentation, embedded systems, and commercial electronics where robust inter-board connectivity is essential.
Engineers will value the quality build, precise contact alignment, and high thermal endurance of this Amphenol Communications Solutions PCB Header. Explore more PCB connectors and wire housings in the EnvMart Electronics Components category or browse Amphenol products for further solutions.
