RIGOL DG2000 Series Function/Arbitrary Waveform Generator | DG2052 | DG2072 | DG2102
Model
Max Sample Rate
Max Output Frequency
Vertical Resolution
Number of Channels
Arbitrary Waveform Length
Specifications
| Display | 4.3-inch TFT color touch screen |
|---|---|
| Brand | Rigol |
| Power Supply | 100 V to 240 V AC (45 Hz to 440 Hz) |
| Model | DG2000 Series |
| Weight | 3.2 kg |
| Output Impedance | 50 Ω |
| Display Resolution | 480 × 272 |
| Sample Rate | 250 MSa/s |
| Channels | 2 |
| Dimensions (W × H × D) | 261.5 x 112 x 318.4 mm |
| Frequency Stability | ±1 ppm |
| Vertical Resolution | 16 bits |
| Amplitude Range | 1 mVpp to 10 Vpp (≤10 MHz), 1 mVpp to 1 Vpp (60 MHz) |
| Phase Noise | -105 dBc/Hz (typical) |
| Built-in Arbitrary Waveforms | 160 types |
| Maximum Sine Output Frequency | 100 MHz |
| Memory Depth per Channel | 16 Mpts |
| Harmonic Order | Up to 8 |
| Jitter | As low as 200 ps |
| Frequency Counter Bandwidth | 240 MHz |
| Frequency Counter Resolution | 7 digits/s |
Key Features
Rigol DG2000 Series Function/Arbitrary Waveform Generator delivers high performance for advanced laboratory and industrial applications.
- Dual-channel generator with up to 100 MHz output frequency.
- High fidelity SiFi II technology ensures low distortion, high-accuracy signals.
- 16-bit vertical resolution and 16 Mpts memory depth per channel for detailed waveforms.
- 250 MSa/s sample rate provides high-speed signal generation.
- Features 160 built-in arbitrary waveforms and advanced harmonic generator up to 8th order.
- Ultra-low jitter (as low as 200 ps) and superior frequency stability (±1 ppm).
- Intuitive 4.3-inch TFT color touch screen for ease of operation.
- Comprehensive analog/digital modulation, including AM, FM, PM, FSK, PSK, PWM, and ASK.
- Integrated 240 MHz frequency counter with 7-digit/s resolution broadens test capabilities.
- USB Host, USB Device, LAN, and USB-GPIB interfaces for versatile connectivity.
Product Description
The RIGOL DG2000 Series Function/Arbitrary Waveform Generator, available in DG2052, DG2072, and DG2102 models, is designed for accurate and versatile signal generation in R&D laboratories, communication testing, automotive electronics, industrial testing, and advanced engineering applications. With dual output channels and model-specific frequencies up to 100 MHz, the series supports synchronised waveform generation for complex electronic testing.
Powered by RIGOL’s SiFi II signal-generation technology, the DG2000 Series provides 16-bit vertical resolution, low signal distortion, and waveform memory up to 16 Mpts per channel. A sampling rate up to 250 MSa/s enables accurate reproduction of high-speed and complex waveforms for circuit development, component validation, and system troubleshooting.
The series includes 160 built-in arbitrary waveforms and advanced sequence-editing functions, allowing users to create customised signals for different test requirements. It also supports harmonic generation up to the eighth order and dual-tone output for advanced signal simulation and frequency-response testing.
- Model-specific output frequencies up to 100 MHz
- Two synchronised output channels
- Sampling rate up to 250 MSa/s
- High 16-bit vertical resolution
- Waveform memory up to 16 Mpts per channel
- RIGOL SiFi II signal-generation technology
- Up to 160 built-in arbitrary waveforms
- Advanced waveform sequence editing
- Harmonic generation up to the eighth order
- Dual-tone signal output
- Frequency accuracy up to ±1 ppm
- Typical phase noise of approximately -105 dBc/Hz
- Jitter as low as 200 ps
- Integrated 240 MHz frequency counter
- 4.3-inch TFT colour touchscreen
- USB Host, USB Device, LAN, and optional USB-GPIB connectivity
- Short-circuit protection for dependable operation
The integrated frequency counter provides measurement capability up to 240 MHz with seven-digit resolution. Its 4.3-inch touchscreen offers convenient graphical control of waveform parameters, channel configurations, frequency, amplitude, phase, modulation, and sequence settings.
USB and LAN interfaces allow the waveform generator to connect with computers, laboratory networks, production equipment, and automated test systems. Optional USB-GPIB support further improves compatibility with established industrial and laboratory setups.
Typical applications include electronic circuit development, laboratory waveform testing, communication-system validation, automotive test benches, sensor simulation, component characterisation, industrial signal verification, manufacturing quality control, equipment maintenance, and engineering education.
The standard package may include the waveform generator, power cord, and user manual; supplied accessories can vary depending on the selected model and supplier configuration.
Available Models: DG2052 | DG2072 | DG2102
Discover more RIGOL function generators, arbitrary waveform generators, signal generators, and professional test and measurement instruments in the Function Generator category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The RIGOL DG2000 Series Function Generator has a maximum output frequency of 100 MHz.
The sample rate of the DG2000 Series Function Generator is up to 250 MSa/s.
The DG2000 Series Function Generator includes 160 built-in arbitrary waveforms.
The vertical resolution of the RIGOL DG2000 Series is 16 bits.
The memory depth per channel for the DG2000 Series Function Generator is 16 Mpts.
The RIGOL DG2000 Series features a 4.3-inch TFT color touch screen for ease of operation.
The weight of the RIGOL DG2000 Series Function Generator is 3.2 kg.
The RIGOL DG2000 Series Function Generator requires a power supply range of 100 V to 240 V AC (45 Hz to 440 Hz).
