RIGOL MSO8000A Series Digital Oscilloscope | MSO8074A | MSO8154A | MSO8204A
Model
Analog Bandwidth
Specifications
| Country of Origin | China |
|---|---|
| Power Consumption | Max. 200 W |
| Display | 10.1-inch capacitive multi-touch |
| Brand | Rigol |
| Power Supply | 100–240 V AC, 45–440 Hz |
| Model | MSO8000A |
| Weight | 4.0 kg (without accessories, approx.) |
| Sampling rate | 10 GSa/s single-channel |
| Display Resolution | 1024 × 600 |
| Interfaces | USB Host ×4, USB Device ×1, LAN, HDMI, AUX, optional USB-GPIB |
| Waveform Capture Rate | ≥600,000 wfms/s |
| Vertical Resolution | 9–12 bits High-Resolution Mode |
| Memory Depth | 500 Mpts analog (single-channel) |
| Timebase Range | 750 MHz: 500 ps/div to 1 ks/div; 1.5/2 GHz: 200 ps/div to 1 ks/div |
| Vertical Sensitivity | 1 mV/div to 10 V/div (1 MΩ), 1 mV/div to 1 V/div (50 Ω) |
| Product Condition | New |
| MPN | MSO8000A |
| Rack Mount | 6U |
| Analog Channels | 4 |
| Bandwidth (50 Ω) | Up to 2 GHz |
| Digital Channels | 16 with RPL2316 logic probe |
| Timebase Resolution | 2 ps |
| Integrated Instruments | Digital Oscilloscope, Logic Analyzer, Spectrum Analyzer, Arbitrary Waveform Generator (optional), Voltmeter, Frequency Counter, Protocol Analyzer |
| Waveform Recording | Up to 450,000 frames |
Key Features
Rigol MSO8000A Mixed Signal Oscilloscope delivers up to 2 GHz bandwidth, advanced debugging for embedded, digital, and analog systems.
- 4 analog and 16 integrated digital channels provide comprehensive mixed-signal debugging.
- Up to 2 GHz analog bandwidth with real-time sampling rates up to 10 GSa/s.
- 7-in-1 instrument integration includes oscilloscope, logic analyzer, spectrum analyzer, and more.
- Large 10.1-inch capacitive multi-touch display for intuitive operation and rapid results analysis.
- Advanced deep memory up to 500 Mpts and a waveform capture rate of ≥600,000 wfms/s.
- UltraVision II technology platform ensures fast processing and analysis.
- Extensive protocol support: serial, I2C, SPI, CAN, MIL-STD, and more (optional decoding and triggers).
- Optional modules for power analysis, eye diagram, and jitter measurements.
- Multiple connectivity: USB, LAN, HDMI, AUX, and optional GPIB.
- Suitable for laboratory, R&D, automotive, industrial, and educational testing environments.
Product Description
The RIGOL MSO8000A Series Digital Oscilloscope, available in MSO8074A, MSO8154A, and MSO8204A models, is designed for advanced debugging and testing of analog, digital, and embedded systems. Suitable for R&D laboratories, electronics development, and manufacturing test environments, the series provides analog bandwidth options up to 2 GHz, four analog channels, and 16 optional digital channels for detailed mixed-signal analysis.
The MSO8000A Series offers real-time sampling rates up to 10 GSa/s and memory depth up to 500 Mpts, enabling accurate signal capture and long-duration waveform analysis. Built on RIGOL’s UltraVision II platform, it delivers waveform capture rates up to 600,000 waveforms per second and advanced triggering capabilities for detecting complex and infrequent signal events.
- Analog bandwidth options up to 2 GHz
- Four analog channels
- 16 digital channels with a compatible logic probe
- Real-time sampling rate up to 10 GSa/s
- Memory depth up to 500 Mpts
- Waveform capture rate up to 600,000 waveforms per second
- Advanced triggering and waveform-analysis functions
- Protocol decoding for RS232/UART, I²C, SPI, CAN, LIN, MIL-STD, and FlexRay
- 10.1-inch capacitive touchscreen for clear waveform visualisation
- USB, LAN, and HDMI connectivity
- Suitable for serial protocol debugging and mixed-signal analysis
The RIGOL MSO8000A Series is suitable for embedded-system development, automotive-electronics testing, industrial signal analysis, manufacturing quality control, and advanced electronics research.
Available Models: MSO8074A | MSO8154A | MSO8204A
Explore more RIGOL digital oscilloscopes and electronic test instruments on EnvMart for industrial, laboratory, and R&D measurement applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Rigol MSO8000A offers up to 2 GHz analog bandwidth, making it suitable for high-frequency signal analysis.
The MSO8000A features 4 analog channels and 16 digital channels, providing extensive mixed-signal debugging capabilities.
The oscilloscope has a maximum real-time sampling rate of 10 GSa/s for single-channel operation.
Yes, the MSO8000A includes multiple connectivity options such as USB, LAN, HDMI, and an optional GPIB interface.
The MSO8000A supports a variety of measurements including voltage, frequency, and protocol analysis, with integrated functions for advanced debugging.
The oscilloscope features a memory depth of up to 500 Mpts for analog signals, allowing for comprehensive waveform analysis.
Yes, the Rigol MSO8000A is suitable for educational settings, as well as for R&D and industrial applications.
It has a large 10.1-inch capacitive multi-touch display with a resolution of 1024 × 600 for intuitive operation.
Yes, optional modules for power analysis, eye diagram, and jitter measurements can be purchased separately.
The oscilloscope weighs approximately 4 kg without accessories, making it relatively portable for laboratory use.
