C & K Push Button Switch Momentary Panel Mount Red Actuator SPDT IP68 32V dc PNP8E3D2C03QE

Name: C & K Push Button Switch Momentary Panel Mount Red Actuator SPDT IP68 32V dc PNP8E3D2C03QE
Brand: C & K
SKU: 419485
Price: 2381.79 INR
Availability: InStock



Category Push Button Switch Brand C & K Condition New

Specifications

Country of Origin	China
Brand	C & K
Model	PNP8E3D2C03QE
IP Rating	IP68
Mount Type	Panel
Series	PNP
Maximum Operating Temperature	85°C
Contact Configuration	SPDT
Switch Configuration	SPDT
Minimum Operating Temperature	-40°C
Panel Cutout Size	12.3 mm
Terminal type	Solder
Standards/Approvals	RoHS
Switch Operation	Momentary
Actuator Colour	Red
Contact DC Voltage	32V dc
Actuator Style	Push Button
Switch Contact Current	5A

Key Features

The push button switch features a momentary switch operation for temporary activation.
It has a 12.3 mm panel cutout size suitable for tight mounting locations.
The contact configuration is SPDT providing single-pole double-throw switching functionality.
Rated IP68, this switch is sealed to protect against dust and water ingress for harsh environments.
It supports a DC contact voltage rating of 32 volts and a contact current of 5 amps.
The actuator style is push button, colored red for clear visual indication.
Designed for panel mounting with solder terminal type for easy wiring.
Operating temperature range is from -40°C to 85°C, enabling use in extreme temperature conditions.

Product Description

C & K PNP8E3D2C03QE push button switch is a high-quality momentary panel mount switch designed with a red push button actuator. It features a single-pole double-throw (SPDT) contact configuration, supporting a contact voltage of 32 volts DC and a current rating of 5 amperes. This IP68 rated switch is sealed against dust and water ingress, making it ideal for use in harsh and demanding industrial, automation, and electrical panel environments.

The switch requires a 12.3 mm panel cutout size and is mounted via panel mount method with solder terminals for secure wiring connections. It operates reliably across a wide temperature range, from -40°C to 85°C, suitable for applications exposed to extreme temperatures.

C & K is renowned for its extensive range of miniature, sub-miniature, and ultra-miniature push button switches used in printed circuit board, surface mount, and panel mount applications. The PNP series pushbuttons are engineered for durability with an IP68 sealing that ensures a long operating life capable of enduring tough environmental conditions.

This push button switch finds application in control grips, off-road panels, heavy equipment, industrial instruments, and lifts. Its momentary action ensures temporary circuit activation, suitable for control functions where the switch returns to its default position when released.

The push button switch features a momentary switch operation for temporary activation. It has a 12.3 mm panel cutout size suitable for tight mounting locations. The contact configuration is SPDT providing single-pole double-throw switching functionality.

Rated IP68, this switch is sealed to protect against dust and water ingress for harsh environments. It supports a DC contact voltage rating of 32 volts and a contact current of 5 amps. The actuator style is push button, colored red for clear visual indication.

Designed for panel mounting with solder terminal type for easy wiring. Operating temperature range is from -40°C to 85°C, enabling use in extreme temperature conditions. Complies with RoHS standards, ensuring environmentally friendly manufacturing.

Choose the C & K PNP8E3D2C03QE push button switch for robust and reliable performance in industrial, automation, and electrical control system applications. Explore more high-quality Push Button Switches in the Electronics & Electricals section of EnvMart.
