TE Connectivity Slide Rotary Coded DIP Switch Through Hole Actuator Slide Model 1825059-6

TE Connectivity 1825059-6 Slide Rotary Coded DIP Switch is a precision component designed for use in electrical, automation, and electronics assemblies requiring rotary encoded input. This switch features a through hole mount type and a slide actuator, making it ideal for PCB integration.

The switch uses a flush actuator slide mechanism offering smooth user operation with high reliability. Its high pressure wiping contact design withstands aqueous and solvent cleaning processes without the need for tape seals, maintaining switch integrity during manufacturing.

It supports soldering processes including vapor phase reflow and wave soldering, enabling compatibility with modern PCB assembly line methods. The contact resistance of 50 milliohms provides low signal loss, while the insulation resistance of 1000 megaohms at 100 Vdc ensures robust electrical insulation between circuits.

With a mechanical life of 1000 cycles, this component offers durability for repetitive switching applications. Featuring a dual-in-line switch design, it fits well for rotary encoded DIP switch arrays used in various control systems.

Flush actuator slide switch designed for ease of operation. High pressure wiping contact suitable for aqueous or solvent cleaning without tape seal. Supports vapor phase reflow and wave soldering conditions without damage.

Contact resistance rated at 50 milliohms for consistent signal transmission. Insulation resistance of 1000 megaohms at 100 Vdc ensures electrical isolation. Mechanical life expectancy of 1000 cycles guarantees durability.

Dual-In-Line configuration supports integration in rotary encoded DIP switch arrays. Ideal for electronics, automation, and electrical assembly applications.

This switch is widely used in industrial automation, electronics manufacturing, signal control, and embedded system applications where precise rotary encoding input is necessary. It supports a diverse range of environments requiring stable electrical performance.
