Microchip Operational Amplifier 80 kHz 5-Pin SC-70 5.5V MCP6V11UT-E/LT

Microchip MCP6V11UT-E/LT Operational Amplifier is a high-precision surface-mount device featuring a gain bandwidth product of 80 kHz. It operates over a supply voltage range from 1.6V to 5.5V, making it versatile for various electronic circuit applications including industrial and automotive electronics.

The device provides a single operational amplifier channel in a compact 5-pin SC-70 package measuring 2.25mm by 1.35mm by 1mm. Its low input bias and offset current ensure accurate signal amplification with minimal error, alongside a low input offset voltage of 8 µV and a slew rate of 0.03 V/µs, ideal for sensitive analog circuits.

Designed for reliability, this amplifier can operate in temperature ranges from -40°C to 125°C, suitable for harsh industrial environments and automotive applications compliant with AEC-Q100 standards. It supports output currents up to 30mA, enabling it to drive loads effectively.

The MCP6V11UT-E/LT is RoHS compliant, fulfilling environmental regulations and making it a sustainable choice for modern electronic designs. It is manufactured in Thailand and designed to integrate seamlessly into surface-mount PCB assemblies.

This operational amplifier operates between 1.6V minimum to 5.5V maximum supply voltage. It has a gain bandwidth product of 80 kHz for precise analog signal amplification. It supports a single channel with low input bias current of 5 pA and input offset current of 50 pA.

Built to endure operating temperatures from -40°C to 125°C, suitable for demanding environments. Features a low input offset voltage of 8 µV and a slew rate of 0.03 V/µs for accurate signal response. The package is a compact 5-pin SC-70 surface-mount type with dimensions 2.25mm length, 1.35mm width, and 1mm height.

This amplifier outputs up to 30mA current and meets the automotive standard AEC-Q100. RoHS compliant ensuring environmental standards are met.

This operational amplifier is ideal for use in electronic equipment requiring stable, low-noise signal amplification such as industrial controls, automotive electronics, instrumentation, and HVAC systems. Its small size and surface-mount configuration facilitate compact PCB layouts.
