Tele Timer Light Switch Timer Relay DIN Rail Mount with 1-Contact, 8 to 230 V DC, 230V AC, 0.5 to 12 min Time Range E1ZT

Tele E1ZT Timer Light Switch Timer Relay is a highly reliable, DIN rail-mounted timer relay designed for industrial and commercial automation applications. This device supports an operating voltage range of 8 to 230 V DC and several AC voltages, including 230, 239, and 8 V AC, making it highly versatile for various electrical installations.

The timer relay features a single normally open (1 NO) contact configuration, suitable for timer and impulse relay functions such as staircase lighting control. The time range is adjustable from 0.5 to 12 minutes for T and TW functions, with extended capabilities up to 60 minutes during pumping operations.

Designed for efficiency, the E1ZT series includes energy-saving functions, retrigger and time extension programmability, and an impulse switch mode selectable option. Its construction ensures low switching noise and high switching capacity with peak inrush current of 80A, ideal for robust electrical loads. The device also incorporates automatic 3/4-wire detection for simplified installation and supports push-button glow lamp loads up to 100mA.

With a compact form factor measuring 6mm length, 87mm height, and 17.5mm width, this relay integrates seamlessly into standard DIN rail assemblies. The terminal type is screw for secure wiring connections. The timer relay meets recognized standards including EN 60669-2-3, DIN 180-158-2, EN 60715, IEC 60721-3-3, VBG 4, and IEC 60664-1, ensuring compliance and quality.

This innovative timer relay is engineered for use in industrial automation, electrical installations in commercial buildings, water pumping systems, and staircase lighting controls. Its robust design accommodates a temperature operating range from -25°C to 55°C and an ingress protection rating of IP40, making it suitable for a wide range of environmental conditions.

Country of origin is Austria, reflecting the quality and precision engineering standards of European manufacturing. The Tele E1ZT timer relay offers reliable, programmable timing control in compact DIN rail format for a variety of automation and switching applications.

Operates with supply voltage from 8 to 230 V DC and multiple AC voltages including 230V, 239V, and 8V AC. Designed for staircase timers and impulse relay functions with programmable time extension. Features low switching noise and supports an 80A peak inrush current.

Includes automatic 3/4-wire detection and supports glowing lamp load up to 100mA. Compact size with 17.5 mm width and mounting on standard DIN rails.

This timer relay is an ideal choice for industrial, automation, building electrical, and HVAC control systems. Browse more Timer Relays and DIN rail mounted automation devices on EnvMart.
