Cosel Low-Profile Isolated PCB Mount DC-DC Converter 15V DC 700mA 36-48V Input 10.5W SIP-8 7-Pin MGS104815
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGS DC/DC Converter, 15V dc/ 700 mA, 48V dc |
| Brand | Cosel |
| Efficiency | 90% |
| Length | 22mm |
| Model | MGS104815 |
| Depth | 12mm |
| Gross Weight | 7g |
| Width | 9.5mm |
| Mount Type | PCB |
| Series | MGS |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-8 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 400mV Pk-Pk |
| Maximum Output Power | 10.5W |
| Maximum Input Voltage | 48V dc |
| Minimum Input Voltage | 36V |
| Number of Pins | 7 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 700mA |
| Output Voltage Adjustment Range | 14.55 to 15.45 V |
| Isolation Voltage | 1kV dc |
| Output Current 2 | 0.7A |
| Output Voltage 2 | 12V |
Key Features
- Designed for PCB mounting with a low-profile SIP-8 package and 7-pin configuration.
- Operates with input voltages from 36V to 48V DC.
- Maintains high efficiency of approximately 90% during operation.
- Features a ripple and noise of 400mV peak-to-peak for stable voltage output.
- Supports an output voltage adjustment range from 14.55V to 15.45V.
- Provides isolation voltage of 1kV DC ensuring safety and noise reduction.
- Rated for use within a wide temperature range from -40°C to 85°C.
- Complies with multiple industrial standards, including UL62368-1, RoHS, CE, and CSA certifications.
Product Description
Cosel MGS104815 DC-DC Converter is a high-quality, low-profile isolated power module for industrial and electronic applications. It delivers a regulated 15V DC output with a current of 700mA, suitable for sensitive electronics requiring stable power supply. The device accepts input voltages ranging from 36V to 48V DC, making it versatile for various DC supply sources.
This converter is designed for PCB mounting, using a space-saving SIP-8 package with 7 pins, ensuring compatibility with standard printed circuit board footprints and ease of integration in compact systems.
The unit operates with an efficiency of approximately 90%, reducing energy losses and thermal generation. Its ripple and noise level is controlled at 400mV peak-to-peak, delivering smooth voltage output with minimal interference to sensitive components.
Output voltage can be finely adjusted between 14.55V and 15.45V to meet precise application requirements. The converter provides a 1kV DC isolation voltage to improve safety, prevent electrical noise transfer, and protect downstream circuitry.
Engineered to function reliably within harsh environments, this module operates between -40°C and 85°C, making it well-suited for industrial, laboratory, and control system applications. Its compliance with international standards such as UL62368-1, RoHS, CE, C-UL, and CSA ensures adherence to quality, safety, and environmental regulations.
Designed for PCB mounting with a compact SIP-8 7-pin package. Input voltage range from 36V to 48V DC supports versatile power sources. Output voltage of 15V DC at 700mA with 10.5W maximum power. High efficiency around 90% reduces energy consumption.
Controlled ripple and noise at 400mV peak-to-peak for stable output. Output voltage adjustable from 14.55V to 15.45V for precision. Isolation voltage of 1kV DC for enhanced safety and noise reduction. Wide operating temperature range: -40°C to 85°C allows use in harsh environments.
Meets multiple global safety and environmental certifications.
This Cosel DC-DC converter is ideal for applications in industrial equipment, telecommunications, test and measurement systems, and power supply modules requiring reliable DC voltage conversion. The compact footprint supports efficient PCB space utilization. For additional technical details, product specifications, and compatible accessories, continue to explore EnvMart's extensive electronics components catalog.
Explore more products in our DC/DC Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model accepts input voltages ranging from 36V to 48V DC.
It provides a regulated output voltage of 15V DC with a current rating of 700mA.
The converter operates with an efficiency of approximately 90%.
The ripple and noise level is controlled at 400mV peak-to-peak.
It offers an isolation voltage of 1kV DC, enhancing safety and reducing noise transfer.
The dimensions of the SIP-8 package are 22mm in length, 9.5mm in width, and 12mm in depth.
This unit operates within a wide temperature range from -40°C to 85°C.
Yes, the output voltage can be adjusted from 14.55V to 15.45V.
It complies with multiple standards including UL62368-1, RoHS, CE, and CSA.
The maximum output power is 10.5W.
This model is designed for PCB mounting.
The gross weight of this converter is 7g.
