Amphenol Communications Solutions D-Sub Connector 9 Way Straight 2.74 mm Pitch Plug-in Male Screw Mount LD09P24A4GX00LF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 5A |
| Model | LD09P24A4GX00LF |
| Mount Type | Plug-in |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | LD |
| Mounting Hardware | Screw |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.74mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | D-Sub |
| D-Sub Shell Size | E |
Key Features
- Supports 9 electrical contacts with a 5A current rating.
- Features a straight orientation for plug-in mounting.
- Constructed with thermoplastic housing and copper alloy contacts plated with gold over nickel.
- Operates reliably from -55°C to 105°C temperature range.
- Connector pitch is 2.74 mm ensuring compatibility with standard D-Sub interfaces.
- Includes screw mounting hardware for secure installation.
- Suitable for telecommunications, industrial, instrumentation, military, and medical applications.
- Meets DIN 41652 and MIL-C-24308 dimensional standards.
Product Description
Amphenol Communications Solutions LD09P24A4GX00LF is a 9 Way Straight D-Sub Connector featuring a 2.74 mm pitch and plug-in mounting type with male screw hardware. This connector is engineered for high reliability and robustness in demanding industrial, telecommunications, laboratory, and military environments.
Its thermoplastic housing and copper alloy contacts plated with gold over nickel ensure durable electrical and mechanical performance. Rated for 5A current and 250V voltage, it operates efficiently across a wide temperature range from -55°C minimum to 105°C maximum.
The D-shaped shell design complies with DIN 41652 and MIL-C-24308 dimensional standards, enabling compatibility with various equipment and interfaces. The plug-in design and screw mounting hardware provide secure connectivity with support for up to 50 mating and unmating cycles.
This connector supports male contact gender with a solder termination type, making it suitable for PCB assembly and robust wiring applications. Its compact 2.74 mm pitch size is ideal for dense electrical layouts.
Ideal for use in telecommunications, industrial instrumentation, commercial electronics, military hardware, and medical devices, this connector ensures excellent signal integrity and dependable performance in harsh environments.
Supports 9 contacts with 5A current rating. Straight orientation with plug-in mounting type. Thermoplastic housing and gold over nickel plated copper alloy contacts. Operates between -55°C and 105°C. Meets DIN 41652 and MIL-C-24308 standards.
Screw hardware mounting for secure connections. Designed for 50 mating/unmating cycles durability. D-shaped shell design for polarization and compatibility. Solder termination suitable for PCB integration.
Choose Amphenol Communications Solutions connectors for industrial, laboratory, construction, and communication applications requiring dependable D-Sub connectivity solutions. Explore related products and variants in the Electronics & Electricals Connectors category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This D-Sub connector supports a current rating of 5A.
It has a voltage rating of 250V.
It operates reliably within a temperature range of -55°C to 105°C.
The connector features a thermoplastic housing and copper alloy contacts plated with gold over nickel.
This model supports 9 electrical contacts.
It utilizes a plug-in mounting type with screw mounting hardware for secure installation.
Yes, it features a solder termination type, making it suitable for PCB assembly.
It meets the DIN 41652 and MIL-C-24308 dimensional standards.
The pitch size of this connector is 2.74 mm.
This connector is designed for up to 50 mating and unmating cycles.
It is suitable for telecommunications, industrial instrumentation, military, and medical applications.
The connector has a male contact gender.
