KEMET R75 Polypropylene Capacitor 5 %, 5.6 nF, 1.6 kV DC, 650V AC Through Hole R75TI156050H3J

KEMET R75TI156050H3J polypropylene film capacitor offers a capacitance of 5.6 nF with a tolerance of 5 %, suitable for high-frequency and medium to high current applications. It is rated for 1.6 kV DC and 650V AC operating voltages, designed with through hole mounting using radial leads positioned with a 15mm pitch and a 25mm lead length.

This capacitor features a plastic self-extinguishing case with thermosetting resin, providing resistance to solvents and ensuring durability. The lead diameter measures 0.8 mm, and the capacitor dimensions are 18mm in length, 11mm in height, and 5mm in width, optimized for PCB installation.

The R75 series capacitor complies with IEC 60286-2 and RoHS standards, including automotive grade AEC-Q200 certification, ensuring reliability and safety. It operates effectively within a temperature range of -55°C to 105°C and exhibits a low dissipation factor of 0.04 % and an equivalent series resistance (ESR) of 142.1 mΩ, which contributes to its high performance in resonant circuits and silicon controlled rectifier applications.

This capacitor is ideal for industrial, laboratory, electronic design, and manufacturing environments where consistent capacitance and voltage handling are crucial. Its tape and reel packaging format facilitates automated assembly processes, making it an excellent choice for high volume production.

Capacitance rated at 5.6 nanofarads suitable for high frequency circuits. 5 % tolerance ensures precision performance in demanding applications. Rated DC voltage of 1.6 kilovolts and AC voltage of 650 volts for robustness.

Through hole mounting type with 15mm lead pitch for reliable PCB attachment. Plastic package case provides self-extinguishing and solvent resistance. Lead length of 25mm and lead diameter of 0.8mm for easy soldering. Compliant with IEC 60286-2 and RoHS standards for quality assurance.

Operating temperature range from -55°C up to 105°C for wide environmental applicability. Explore more in our Film Capacitors category for additional components and accessories suitable for electronics manufacturing and repair.
