KEMET R75 Polypropylene Capacitor 18nF 5% Tolerance 2kV DC 700V AC Through Hole R75UI218050H3J

Free Delivery in India | Lowest Global Shipping Charges

KEMET R75 Polypropylene Capacitor 18nF 5% Tolerance 2kV DC 700V AC Through Hole R75UI218050H3J

Name: KEMET R75 Polypropylene Capacitor 18nF 5% Tolerance 2kV DC 700V AC Through Hole R75UI218050H3J
Brand: KEMET
SKU: 411922
Price: 0.62 USD
Availability: InStock



Category Capacitors Brand KEMET Condition New

Specifications

Country of Origin	China
Brand	KEMET
Height	16mm
Length	18mm
Model	R75UI218050H3J
Packaging	Tape & Reel
Width	10mm
Mount Type	Through Hole
Series	R75
Maximum Operating Temperature	105°C
Tolerance	5 %
Capacitance	18nF
Minimum Operating Temperature	-55°C
Dissipation Factor	0.04%
Lead Length	25mm
Standards/Approvals	IEC 60286-2, RoHS
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	700V ac
Rated DC Voltage	2kV dc
Lead Pitch	15mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200
Equivalent Series Resistance ESR	44.2mΩ

Key Features

Features a radial lead polypropylene film dielectric for high reliability.
Encapsulated in a self-extinguishing plastic case with thermosetting resin.
Rated for operation between -55°C to 105°C operating temperature range.
Designed for high frequency and medium to high current use cases.
Complies with IEC 60286-2 and RoHS standards.
Package type is Tape & Reel for automated assembly.
Lead pitch measures 15mm and lead length is 25mm for through hole mounting.
Automotive standard AEC-Q200 certified for quality and reliability.

Product Description

KEMET R75UI218050H3J polypropylene capacitor is a 18nF, 5% tolerance film capacitor designed for robust electrical performance in demanding industrial and electronic applications. It supports a rated DC voltage of 2kV and AC voltage of 700V, making it ideal for high voltage circuits requiring stability and durability.

The component is mounted via through-hole technique with a 15mm lead pitch and 25mm lead length, ensuring secure soldering on printed circuit boards. The capacitor is built with metallized polypropylene film dielectric enclosed within a plastic case that is solvent resistant and self-extinguishing, enhancing safety and longevity.

This capacitor is suited for silicon controlled rectifiers, resonant circuits, and high frequency medium to high current applications where low ESR and dissipation factor are critical. It fulfills IEC 60286-2 and RoHS compliance standards and carries the automotive AEC-Q200 certification, ensuring its suitability for automotive and other high reliability environments.

Operating temperature ranges from -55°C to 105°C allow usage in a wide variety of industrial environments. Its compact size with 18mm length, 16mm height, and 10mm width facilitates integration into space-constrained designs.

Radial lead polypropylene film dielectric construction. Self-healing and solvent resistant encapsulation for electrical safety. AEC-Q200 automotive qualification for enhanced reliability. Low ESR and dissipation factor supporting efficient electrical performance.

Through hole mount type using 0.8mm diameter leads. Tape & Reel packaging suitable for automated PCB assembly lines. Wide operating temperature from -55°C to 105°C for versatile applications. RoHS compliant and IEC 60286-2 certified for environmental and quality standards.

Optimized for use in resonant circuits and high frequency switching applications.

This KEMET R75 series polypropylene capacitor is ideal for industrial electronic systems, automotive circuits, power electronics, instrumentation, and HVAC control systems. Explore robust film Capacitors at EnvMart for all your industrial-grade component requirements.
