TDK-Lambda DC/DC Converter , 12V DC Output, 1.67A, 9V to 36V DC Input, 20W, PCB Mount, DIP Package, Operating PXE20-24WS12

TDK-Lambda PXE20-24WS12 is a high-performance DC/DC converter designed for efficient voltage conversion applications in industrial, electronic, and power management systems. This model provides a regulated 12V DC output with a maximum current of 1.67A and supports wide input voltage ranges from 9V to 36V DC, accommodating various power supply sources.

The converter is housed in a compact DIP package with a PCB mount type, featuring 7 pins for easy and secure integration into electronic assemblies. It boasts low ripple and noise of 75mV, delivering clean and stable power necessary for sensitive electronic components.

Engineered for reliability, it has an operating temperature range from -40°C up to 85°C, allowing it to perform under harsh environmental conditions. The device offers high isolation voltage rated at 1.6kV, ensuring electrical safety and minimizing interference.

The PXE20-24WS12 achieves an efficiency of about 81%, contributing to energy-saving operation and minimal heat generation. Its robust MTBF of nearly two million hours underscores its long service life and dependable performance in continuous industrial use.

Measuring 50.8mm in length, 40.6mm in width, and 10.2mm in depth, this converter is suitable for compact electronic designs and power supply units. The product originates from Taiwan, Province Of China, reflecting stringent manufacturing and quality control processes.

Delivers a maximum output power of 20 watts for efficient power supply. Compact DIP package with 7 pins and PCB mount type for easy integration. Supports broad operating temperature from -40°C up to 85°C, ensuring reliability in harsh environments.

Features a high isolation voltage of 1.6kV for safety and noise reduction. Low ripple and noise at 75mV ensure clean output power. Input voltage range supports 4:1 ratio, allowing flexible DC source inputs. High MTBF of 1,976,000 hours for extended operational life.

Efficiency is approximately 81%, optimizing energy consumption. Dimensions: length 50.8mm, width 40.6mm, depth 10.2mm for compact design fit. Made in Taiwan, Province Of China, assuring quality manufacturing standards.

This DC/DC Converter is ideal for electronic components, power supply systems, industrial automation, and other applications requiring stable voltage conversion with high reliability and efficiency. Browse EnvMart’s extensive range of industrial and electronic components for more advanced and specialized power converters.
