TDK-Lambda DC/DC Converter 15V DC Output 670mA 10W PCB Mount DIP Package PXD10-48WS15

TDK-Lambda PXD10-48WS15 DC/DC Converter is a compact and efficient power supply module designed for industrial, telecommunications, mobile telecom, test equipment, and other electronic applications requiring stable 15V output at 670mA current. It operates from a broad input voltage range of 18V to 75V DC within a robust DIP package tailored for PCB mounting.

This converter provides reliable performance with features such as 1.6kV isolation voltage for enhanced safety and noise suppression, short circuit and over voltage protections, and a high Mean Time Between Failures (MTBF) of approximately 1,976,000 hours. It maintains low ripple and noise output at around 50mV, ensuring precise and stable voltage supply for sensitive electronics.

The device supports an input voltage ratio of 4:1 allowing flexible power source options. Its operating temperature range from -40°C to 105°C makes it suitable for demanding environments and extended reliability in harsh conditions. The physical dimensions are compact with a length of 2 inches, width of 1 inch, and a depth of 10.2 mm, weighing roughly 27 grams, facilitating easy integration into existing PCB designs.

Due to its high efficiency of 0.84% and protective features, the PXD10-48WS15 model is highly recommended for applications including telecommunications infrastructure, industrial automation, mobile communication devices, and rigorous testing setups requiring steady DC power conversion.

Wide input voltage range from 18V to 75V DC catering to various power sources. Single output delivering 15V DC at 670mA current with 10W power rating. PCB mount DIP package with six pins for secure electrical connections.

High isolation voltage of 1.6kV ensuring safety and noise reduction. Protective functions include short circuit and over voltage safeguards. Reliable MTBF rating of 1,976,000 hours for long-term usage. Low ripple and noise output of 50mV suitable for sensitive electronics.

Wide operating temperature range from -40°C to 105°C for diverse environments. Compact dimensions (2in x 1in x 10.2mm) and light weight (~27 grams). Efficiency of 0.84% contributing to energy savings.

This product is manufactured in Taiwan, Province Of China, under the respected TDK-Lambda brand known for quality power conversion solutions. It is ideal for use in various industrial, telecommunications, HVAC, manufacturing, and laboratory applications requiring reliable DC power conversion with wide input ranges and protection features.
