SMC 3 Pin M8 Direct PNP Solid State Switch Pneumatic Cylinder & Actuator Switch 28V dc LED Indicator D-Y7P

SMC D-Y7P is a 3 Pin M8 Direct PNP Solid State Switch designed for pneumatic cylinders and actuators. It operates on 28V dc and includes an LED indicator to ensure visibility of switching status. The switch belongs to the D-Y7 series and provides reliable sensing for automation systems.

This solid state switch has a wide operating temperature range from -10°C to 60°C, making it suitable for demanding industrial environments. It features an IP67 ingress protection rating, ensuring resistance against dust and water ingress, which is critical in pneumatic and actuator applications.

The device supports a maximum switching current of 40mA and is compatible with circuit elements such as IC circuits, relays, and PLCs. The compact dimensions of 18mm height, 15.5mm width, and 46mm depth allow easy integration into various pneumatic setups.

Its electrical connection is a 3-pin M8 connector, and the operation is PNP type, providing positive switching outputs with a 500mm lead wire for ease of installation.

Applications include industrial automation, pneumatic control systems, and actuator monitoring. The switch is manufactured in Japan meeting RoHS and IEC 529 standards, ensuring high quality and environmental compliance.

The switch operates at 28 volts DC with PNP output and 3-pin M8 electrical connection. It features an IP67 rating for dust and water resistance. Operating temperature ranges from -10°C to 60°C ensuring reliable function in varied environments.

Equipped with a red LED indicator for operational status visibility. Compatible with MY1B, CXS, MY1HT, MY1C, MY1M, and CXSW models. Maximum switching current is 40mA suitable for IC circuits, relays, and PLC applications.

Compact dimensions: height 18mm, width 15.5mm, depth 46mm. This product is ideal for industrial, manufacturing, pneumatic, and automation use cases. For more Pneumatic Cylinder Switches, explore our expanded collection.
