Littelfuse Silicon Controlled Rectifier SCR 200 V 0.25 A Surge 7 A SOT-23 Package NYC0102BLT1G
Specifications
| Country of Origin | India |
|---|---|
| Brand | Littelfuse |
| Model | NYC0102BLT1G |
| Mount Type | Surface |
| Series | NYC0102BL |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | Pb-Free, RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Rated Average On-State Current Irms | 0.25A |
| Thyristor Type | SCR |
| Repetitive Peak Reverse Voltage VDRM | 200V |
| Surge Current Rating | 7A |
| Maximum Gate Trigger Current Igt | 200μA |
| Maximum Holding Current Ih | 6mA |
| Maximum Gate Trigger Voltage Vgt | 0.8V |
| Peak On-State Voltage | 1.7V |
| Repetitive Peak Off-State Current | 100μA |
Key Features
- Designed for phase control applications with a surge current rating of 7 A.
- Features a maximum gate trigger current of 200 microamperes for precise activation.
- Operates reliably from -40°C to 125°C for automotive and industrial environments.
- Automotive-grade device compliant with AEC-Q101 standards ensuring high reliability.
- Compact surface-mount form factor allows for space-saving PCB designs.
- Low peak on-state voltage of 1.7 V reduces power loss during conduction.
- RoHS and Pb-Free compliant meeting environmental standards.
- Three-pin configuration facilitating easy integration into circuits.
Product Description
Littelfuse NYC0102BLT1G Silicon Controlled Rectifier (SCR) is a reliable semiconductor device designed for switching and phase control applications in industrial and automotive electronics. Featuring a repetitive peak reverse voltage of 200 V and a rated average on-state current of 0.25 A, this device is packaged in a compact SOT-23 surface-mount package allowing efficient PCB utilization.
This SCR supports surge currents up to 7 A and operates efficiently with a low peak on-state voltage of 1.7 V, reducing power dissipation. The maximum gate trigger current is 200 microamperes, enabling precise control with minimal drive power.
Engineered to operate reliably within a wide temperature range of -40°C to 125°C, it is compliant with the automotive standard AEC-Q101, highlighting its suitability for harsh environments and automotive applications. Its Pb-Free and RoHS compliance ensure it meets current environmental regulations.
The device features a three-pin configuration for easy incorporation into electronic circuits, making it suitable for power control modules, lighting controls, and other switching applications in industrial, automotive, and manufacturing sectors.
Designed for phase control circuits and switch mode power supplies. Compact SOT-23 surface mount package for space-limited designs. High surge current rating protects against transient conditions. Wide operating temperature range meets automotive requirements.
Environmentally compliant with Pb-Free and RoHS standards. Low gate trigger current enables energy-efficient control. AEC-Q101 qualification supports automotive and industrial usage. Three-terminal configuration facilitates straightforward implementation.
Explore the wide range of semiconductor devices available at EnvMart for your electronic component needs. Our catalog includes leading brand Littelfuse products like the NYC0102BLT1G SCR for diverse industrial and automotive applications.
Explore more products in our Thyristors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Littelfuse NYC0102BLT1G has a maximum repetitive peak reverse voltage of 200 V.
This model has a rated average on-state current of 0.25 A.
It supports a surge current rating of 7 A.
The maximum gate trigger current is 200 microamperes (200 μA).
It operates reliably within a temperature range of -40°C to 125°C.
The device is packaged in a compact SOT-23 surface-mount package.
It is compliant with Pb-Free and RoHS environmental standards.
This SCR features a three-pin configuration.
It complies with the AEC-Q101 automotive standard.
The peak on-state voltage is 1.7 V, which helps reduce power loss during conduction.
It is designed for phase control applications and switch mode power supplies in industrial and automotive settings.
The maximum holding current is 6 mA.
