onsemi DC Input Phototransistor Output Surface Mount 8-Pin SOIC Optocoupler MOC206R2M

onsemi MOC206R2M is a DC input optocoupler featuring a phototransistor output and surface mount 8-pin SOIC package, designed for reliable electrical isolation in electronic circuits. It supports a maximum forward voltage of 1.5 V and accepts up to 60 mA input current, enabling effective signal transmission without electrical noise infiltration.

This optocoupler provides an isolation voltage of 2500 V AC, ensuring protection in sensitive industrial and consumer electronic environments. Its operating temperature range from -40°C to 100°C makes it suitable for various operating conditions across industrial, automotive, and consumer electronics applications.

The device exhibits typical rise and fall times of 3.2 µs and 4.7 µs, allowing quick switching and signal integrity. Its current transfer ratio ranges between 40% and 200%, facilitating the amplification of input signals for accurate output control.

Packaged in tape and reel, the MOC206R2M supports automated manufacturing processes, enhancing production efficiency and scalability. Certified by VDE and UL standards, this component adheres to rigorous quality and safety benchmarks.

This optocoupler is ideal for electrical isolation in applications such as signal isolation in industrial automation, consumer electronics devices, telecommunications equipment, and power supply circuits. Its robust specifications deliver dependable performance in environments requiring precise control and safety isolation.

Features a DC input current type suitable for precise switching applications. Offers a maximum forward voltage of 1.5 V for efficient operation. Maximum input current rating of 60 mA ensures robust control signal handling.

Isolation voltage up to 2500 V AC protects circuits from high voltage spikes. Wide operating temperature range from -40°C to 100°C for versatile environmental suitability. Typical rise and fall times of 3.2 µs and 4.7 µs respectively for fast response.

Current transfer ratio ranging from 40% minimum to 200% maximum enhances signal fidelity. Packaged in tape and reel format suitable for automated assembly processes. Complies with VDE and UL safety standards for certified quality assurance.

Part of the MOC series by onsemi optimized for reliable optical isolation. Explore our extensive range of premium Optocouplers and electronic components at EnvMart for all your industrial, laboratory, and manufacturing needs.
