Panasonic Through Hole High Frequency Relay 24V DC Coil 3 GHz Max Coil Frequency SPDT ARS1124

Panasonic ARS1124 is a through hole high frequency relay featuring a 24V DC coil with a maximum coil frequency capability of up to 3 GHz. This SPDT relay is part of Panasonic's ARS series, designed for microwave switching with excellent high frequency characteristics.

The relay exhibits a coil resistance of 2880 ohms and a contact resistance of 100 milliohms, providing efficient electrical switching performance. With an insertion loss of just 0.5 dB and an isolation of 30 dB, it ensures minimal signal degradation at microwave frequencies.

Measuring 14 mm in length and 7.2 mm in height, this relay's compact super miniature design allows integration into space-constrained layouts. The coil power rating is 200 mW, which supports energy-efficient operation over extended periods.

Constructed with gold-plated contacts, the ARS1124 relay assures reliable long-term contact integrity and reduced corrosion. It operates within a broad temperature range from -40°C to 70°C, making it suitable for various industrial environments.

This latching relay is through-hole mounted with solder-type terminals for sturdy PCB attachment, enhancing mechanical stability. It is suitable for applications in broadcasting, video systems, measurement equipment, mobile phone base stations, and communications devices requiring precise high frequency relay switching up to 3 GHz.

Country of Origin: Japan. This relay features a single-pole double-throw (SPDT) contact configuration for flexible signal switching. It has a coil resistance of 2880 ohms and contact resistance of 100 milliohms ensuring efficient electrical performance.

The relay provides an insertion loss of 0.5 dB and an isolation of 30 dB suitable for microwave frequency applications. Designed with a compact form factor measuring 14 mm length and 7.2 mm height for space-saving PCB layouts.

The coil power consumption is low at 200 mW, making it energy efficient for prolonged use. This latching type relay operates reliably within a temperature range from -40°C to 70°C. It is manufactured using gold-plated contacts to ensure durability and reduce contact oxidation.

The terminal type is solder and the relay is through-hole mounted for robust mechanical stability. Ideal for broadcasting, video, measurement, mobile phone base stations, and communications applications requiring high frequency signal control.

Explore more Panasonic Relays and other industrial electronics components at EnvMart for advanced electrical and automation system solutions.
