ABB Miniature Circuit Breaker 1-Pole 40A Type C, 253V AC, 72V DC, 6kA Breaking Capacity 2CDS251001R0404 - S201C40

ABB 2CDS251001R0404 - S201C40 Miniature Circuit Breaker, 1-Pole, 40A, Type C, rated at 253V AC and 72V DC, is engineered to provide effective and reliable electrical circuit protection in commercial, industrial, and residential environments. This model from the System Pro M Compact series combines advanced electromechanical technology with a compact design for easy DIN rail installation.

This miniature circuit breaker offers a breaking capacity of up to 6kA, providing robust protection against short circuits and overloads to prevent electrical hazards. Its Type C tripping characteristic ensures suitable response times for typical commercial and industrial loads, enhancing circuit safety.

The device features a dual tripping mechanism comprising both thermal and electromagnetic elements to provide superior protection against sustained overloads and instantaneous faults. Cage terminal connections facilitate secure and stable wiring, minimizing installation errors and maintenance needs.

With compact dimensions of 88mm height, 76mm depth, and 17.5mm width, this breaker fits neatly into electrical panels and distribution boards designed to IEC/EN 60898-1 and IEC/EN 60947-2 standards. Its IP20/IP40 rating safeguards internal components against ingress of solid objects, making it durable in standard industrial conditions.

Typical applications include commercial electrical distribution systems, industrial machinery protection, automation system safety, and residential electrical circuits meeting IEC standards. Installing on a standard DIN rail ensures reliable mechanical and electrical connection.

Type C tripping characteristic offers precise overload protection in varied applications. Thermal and electromechanical tripping mechanisms provide comprehensive circuit safeguarding. Compact design allows efficient DIN rail installation in crowded panel layouts.

6kA breaking capacity offers elevated protection against short circuit risks. Cage terminal type ensures secure wiring and easy maintenance. Complies with IEC/EN 60898-1 and IEC/EN 60947-2 international standards. Dimensioned 88mm (H) × 76mm (D) × 17.5mm (W) for optimized panel integration.

IP20 and IP40 ratings protect against solid particle ingress in industrial settings.

For those seeking dependable circuit protection solutions, ABB’s System Pro M Compact Miniature Circuit Breaker 2CDS251001R0404 - S201C40 represents an ideal choice, combining advanced safety features with flexibility and compliance to international standards. Browse additional ABB electrical protection devices on EnvMart to find compatible products for your industrial or commercial projects.
