Lovato Electric Modulo Miniature Circuit Breaker 4-Pole 10A Type D 400V AC 10 kA Breaking Capacity P1MB4PD10

Lovato Electric P1MB4PD10 miniature circuit breaker is engineered for high-reliability protection in industrial, commercial, and residential electrical installations. This 4-pole circuit breaker supports a current rating of 10 amperes and operates at an AC voltage of 400 volts. With a Type D tripping characteristic and a breaking capacity of 10 kA, it provides robust protection against short circuits and overloads with fast interruption.

The device is designed with a thermal magnetic tripping mechanism that combines thermal overload protection with magnetic instantaneous trip functionality for superior performance. Its screw terminal type ensures secure electrical connections for enhanced safety and reliability in distribution boards and electrical panels.

Mounted easily on standard DIN rails, this compact circuit breaker features dimensions of 86.5 mm height, 72 mm width, and 80 mm depth, accommodating various electric cabinet designs. The positive indication flag window assists in quick visual status verification of the circuit breaker’s operation.

Rated with an insulation voltage of 440 volts and an impulse withstand voltage of 4 kV, it meets stringent international safety standards including UL 1077, CSA, cURus, EAC, IEC/EN/BS 60898-1, and IEC/EN/BS 60947-2. The IP20 rating grants protection against solid objects, rendering it suitable for indoor electrical equipment applications.

Its instantaneous break time ensures rapid fault clearance to minimize damage risk to electrical systems. Manufactured in Italy, this miniature circuit breaker is designed for use in industrial automation, electrical distribution, construction projects, and building management systems where reliable circuit protection is critical.

Equipped with a thermal magnetic tripping mechanism for reliable protection. Compact design suitable for DIN rail mounting in electrical panels. Features a positive indication flag window for easy operational status check.

Rated insulation voltage of 440 volts and impulse withstand voltage of 4 kV. Includes screw terminal type connections ensuring secure wiring. IP20 rated for protection against solid objects but no protection against liquids.

Manufactured in Italy adhering to multiple international standards including UL 1077 and IEC/EN/BS 60898-1. Dimensions of 86.5 mm height, 72 mm width, and 80 mm depth make it suitable for standard compact installations. Instantaneous break time ensures quick response to faults.
