ABB System Pro M Compact S200 Miniature Circuit Breaker 4-Pole 13A Type B 400V AC 12V DC 6kA 2CDS254001R0135 S204-B13

The ABB System Pro M Compact S200 miniature circuit breaker model 2CDS254001R0135 S204-B13 is a high-quality electrical protection device designed for industrial and commercial applications.

This 4-pole miniature circuit breaker provides a nominal current rating of 13 amperes with type B tripping characteristics offering precise overload and short circuit protection. It supports alternating current voltage up to 400V AC and direct current voltage up to 12V DC, making it versatile for AC and DC systems.

The breaker features a breaking capacity of 6 kA at 230/400 V AC, which ensures effective interruption of fault currents.

The electromechanic thermal tripping mechanism combines a delayed thermal response for overload situations and an immediate electro mechanic response for short circuit events, enhancing circuit safety.

The compact design with dimensions of 70 mm width, 88 mm height, and 69 mm depth allows easy integration into standard DIN rail mount electrical panels, with screw-type terminals for secure connections.

This device holds an IP20 protection rating, protecting internal components from solid objects larger than 12 mm, suitable primarily for indoor installations. Complying with international standards IEC/EN 60898-1, IEC/EN 60947-2, and UL1077, it guarantees reliable performance and compliance with industry norms.

The product is designed with sustainability in mind, featuring disassemblable components that support recycling and better end-of-life management. It is manufactured in Germany, maintaining high quality and precision.

Its operational ambient temperature range spans from -25 to +55 °C while storage temperatures vary from -40 to +70 °C, ensuring durability in various environments. Supports rated AC voltage of 400V and DC voltage of 12V.

Has a breaking capacity of 6 kiloamperes ensuring reliable protection. Mounts on a DIN rail with screw terminal type connection. Complies with IEC/EN 60898-1, IEC/EN 60947-2 and UL1077 standards for safety and performance.

Designed with an electromechanic thermal tripping mechanism for overload and short circuit protection. Constructed with a compact 70mm width, 88mm height, and 69mm depth form factor. Provides protection degree of IP20 suitable for indoor electrical panel installations.

Operates effectively in ambient temperatures from -25 to +55 °C and stores safely between -40 to +70 °C. Manufactured in Germany with focus on sustainability and disassembly.

Ideal for electrical distribution, automation panels, and industrial control systems, this Miniature Circuit Breaker provides critical protection to electrical circuits safeguarding equipment and personnel.
