Bourns PV Series Plastic-Encapsulated Surface Mount Varistor 100 V 680 pF 5 A Clamping 165 V 4032 PV60K4032R2

Bourns PV60K4032R2 is a plastic-encapsulated varistor designed for surface mounting to protect electronic equipment against voltage surges in low and medium voltage regions. It features a capacitance of 680 pF, a clamping current of 5 A, and a clamping voltage of 165 V, making it suitable for transient voltage suppression applications.

The varistor has a varistor voltage rating of 100 V and supports a maximum AC voltage of 60 V and maximum DC voltage of 85 V. Its compact 4032 package size with dimensions approximately 10 mm length and 4.7 mm thickness and depth allows for efficient PCB layout and space-saving designs.

The device operates reliably within a temperature range from -40°C to 85°C. It is encapsulated in a UL 94 V-0 rated non-flammable thermoplastic material that offers safety and durability. Contacts are made from tinned copper sheet to ensure good solderability and conductivity, optimized for automated assembly with tape and reel packaging.

The maximum surge current rating of 1.2 kA provides protection against high transient current events, suitable for a range of industrial, consumer electronics, and power supply applications. This varistor complies with RoHS and UL standards, confirming its quality and safety credentials.

Bourns PV60K4032R2 is expertly manufactured in Slovenia, ensuring consistent performance and durability. The component is ideal for engineers and designers focusing on surge protection in circuit designs across electronic devices and industrial equipment.

Designed for protecting electronic circuits against voltage surges in low to medium voltage applications. Capacitance of 680 pF and varistor voltage of 100 V ensure effective transient voltage suppression. Thermoplastic encapsulation is UL 94 V-0 rated and non-flammable for enhanced safety.

Compact 4032 surface mount package suitable for automated PCB assembly processes. Wide operating temperature range from -40°C to 85°C supports diverse environmental conditions. Maximum surge current capacity of 1.2 kA protects sensitive circuits from transient spikes.

Tinned copper sheet contacts improve solderability and reliability of electronic connections. Compliant with RoHS and UL standards guarantees environmental compliance and safety. Explore Bourns components and Varistors at EnvMart for reliable surge protection solutions catering to electronics, industrial, and power supply applications.
