Phoenix Contact IMC 1.5/4-STGF-3.81 Series Pluggable Terminal Block, 4-Contact, 3.81 mm Pitch, Screw Connection 1858057
Specifications
| Country of Origin | Poland |
|---|---|
| Voltage | 320V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 8A |
| Length | 17.9mm |
| Model | 1858057 |
| Depth | 11.1mm |
| Width | 25.63mm |
| Housing Material | Polyamide |
| Series | IMC 1.5/4-STGF-3.81 |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 4 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.14mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screw |
| PCB connector, nominal current | 8 A, rated voltage (III/2): 160 V, number of positions: 4, pitch: 3.81 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin |
Key Features
- Designed for PCB mounting in electrical and electronic applications.
- Equipped with 4 contact points for secure connectivity.
- Pitch spacing of 3.81 mm to suit compact circuit layouts.
- Operates at nominal current of 8 A and rated voltage up to 320 V.
- Constructed with green polyamide housing for durability and insulation.
- Supports wire sizes from 0.14 mm² to 1.5 mm² (28 to 16 AWG).
- Features straight orientation with screw connection method using tension sleeve.
- Compact dimensions of 17.9 mm length, 25.63 mm width, and 11.1 mm depth.
Product Description
Phoenix Contact 1858057 is a high-quality pluggable terminal block from the IMC 1.5/4-STGF-3.81 series, engineered to provide reliable electrical connections in industrial and electronic PCB applications. This component features 4 contacts arranged in a single row with a 3.81 mm pitch, making it ideal for compact assemblies requiring precise wiring solutions.
The terminal block supports a nominal current of 8 A and a rated voltage of 320 V, suitable for a range of control and signal circuits. Its green polyamide housing ensures effective insulation and mechanical durability, while the tin-coated contact surfaces provide corrosion resistance and stable connectivity.
The device is designed for screw connection with a tension sleeve, allowing secure wire clamping and easy installation. It supports wire sizes from 0.14 mm² (28 AWG) up to 1.5 mm² (16 AWG), accommodating various cable specifications. The straight orientation facilitates straightforward PCB mounting, measuring 17.9 mm in length, 25.63 mm in width, and 11.1 mm in depth, providing a compact form factor for space-sensitive applications.
Manufactured in Poland, this terminal block complies with RoHS directives, ensuring it is free from hazardous substances and suitable for environmentally conscious designs. It is widely used in industrial automation, control systems, electrical panels, and other areas requiring robust and dependable electrical connectors.
Designed for PCB mounting in electrical and electronic applications. Equipped with 4 contact points for secure connectivity. Pitch spacing of 3.81 mm to suit compact circuit layouts. Operates at nominal current of 8 A and rated voltage up to 320 V.
Constructed with green polyamide housing for durability and insulation. Supports wire sizes from 0.14 mm² to 1.5 mm² (28 to 16 AWG). Features straight orientation with screw connection method using tension sleeve. Compact dimensions of 17.9 mm length, 25.63 mm width, and 11.1 mm depth.
Complies with RoHS environmental standards. Manufactured in Poland ensuring quality and conformity. Explore Phoenix Contact products and Pluggable Terminal Blocks on EnvMart for efficient electrical connection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a nominal current of 8 A.
The rated voltage is up to 320 V.
It supports wire sizes from 0.14 mm² (28 AWG) to 1.5 mm² (16 AWG).
The pitch spacing is 3.81 mm.
It measures 17.9 mm in length, 25.63 mm in width, and 11.1 mm in depth.
It is equipped with 4 contacts.
It features a screw connection method with a tension sleeve for secure wire clamping.
It is constructed with green polyamide housing for insulation and durability.
It is manufactured in Poland.
It complies with RoHS environmental standards, ensuring it is free from hazardous substances.
It has a straight orientation, making it suitable for straightforward PCB mounting.
It belongs to the IMC 1.5/4-STGF-3.81 series.
