HARTING D-Sub 15 Way Right Angle Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock Female 09682535613
Specifications
| Country of Origin | China |
|---|---|
| Brand | HARTING |
| Orientation | Right Angle |
| Current | 6.5A |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Thermoplastic |
| Contact Material | Copper Alloy |
| Series | D-Sub |
| Mounting Hardware | 4 to 40 UNC Screw Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Steel |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | D-Sub |
Key Features
- Features 15 female contacts with copper alloy material.
- Rated for a maximum current of 6.5A ensuring strong electrical performance.
- Right angle orientation designed for through-hole mounting.
- Mounting hardware includes 4 to 40 UNC screw lock for secure installation.
- Constructed with fibreglass reinforced thermoplastic housing for durability.
- Operates reliably between -55°C to 125°C temperature range.
- Termination type is solder for secure connection.
- Comes with a stamped and angled female contacts configuration.
Product Description
HARTING 09682535613 D-Sub Connector is a high-quality 15 way right angle female connector designed for through-hole mounting with 4 to 40 UNC screw lock hardware. It features copper alloy female contacts within a fibreglass reinforced thermoplastic housing, delivering durability and reliable electrical connectivity.
Rated for a current of 6.5A, this connector operates efficiently within a wide temperature range from -55°C to 125°C. The solder termination type ensures a strong and lasting electrical connection suitable for industrial, electronics manufacturing, telecommunications, and control systems.
The robust metal shell and extra grounding pin provide enhanced mechanical protection and electrical safety. This connector is commonly used in electronic devices requiring secure, high-quality D-Sub miniature sockets with stamped and angled female contacts.
Its performance level S2 and US footprint make it compatible with many standard applications in electronic assembly and industrial environments. The mounting flange with screw lock further secures the connector to panels.
Features 15 female copper alloy contacts. Supports a maximum current rating of 6.5A. Reliable right angle orientation and through-hole mounting style. Durable fibreglass reinforced thermoplastic housing. Operating temperature range from -55°C to 125°C.
Secure 4 to 40 UNC screw lock mounting hardware included. Solder termination type for strong connections. Steel contact plating for corrosion resistance. Manufactured in China following D-Sub series standards.
This connector is designed for industry professionals requiring reliable and durable miniature D-Sub Connectors for electronic and power connectors in industrial, manufacturing, and telecommunications applications.
Explore a wide range of connectors and electrical components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This D-Sub connector is rated for a maximum current of 6.5A, ensuring strong electrical performance.
It operates reliably within a temperature range from -55°C to 125°C.
The housing is made from fibreglass reinforced thermoplastic, and the contacts are constructed from copper alloy with steel plating for corrosion resistance.
This model features a through-hole mounting style and includes 4 to 40 UNC screw lock hardware for secure installation.
It uses solder termination for secure electrical connections.
This connector has 15 female contacts.
It features a right angle orientation designed for through-hole mounting.
It is commonly used in industrial, electronics manufacturing, telecommunications, and control systems.
This connector is manufactured in China.
This model is a D-Sub connector with female contacts.
It includes a robust metal shell and an extra grounding pin for enhanced mechanical protection and electrical safety.
It comes with a stamped and angled female contacts configuration.
