Cosel Isolated Dual Output DC/DC Converter 24V ±24V DC, 450mA Output, 12V/9V Input, 10.8W, DIP Package, PCB Mount SUTW101212

Cosel SUTW101212 is an industrial-grade isolated dual output DC/DC Converter delivering precise +24V and -24V DC outputs at 450mA from a compact DIP package designed for PCB mounting. It operates efficiently with input voltages of 9 to 12V DC, producing a maximum output power of 10.8W.

This converter is part of the SUTW Series, characterized by the absence of built-in aluminium or tantalum electrolytic capacitors, which enhances reliability in demanding environments. The unit achieves an efficiency of 86%, benefiting industrial and commercial applications where energy efficiency and compact form factor are critical.

Designed for rugged industrial use, it supports a wide operating temperature range from -40°C to 85°C, making it suitable for applications in harsh environments such as automation controls, telecommunications, instrumentation, and manufacturing equipment.

Features include built-in remote ON/OFF functionality, adjustable output voltage within ±22.8V to ±25.2V DC, and comprehensive overcurrent protection, ensuring operational safety and flexibility. It provides a high isolation voltage of 500V AC to reduce noise and protect sensitive electronics.

The device is cooled by convection or forced air, supporting through-hole mounting on PCBs, and includes 7 pins for reliable electrical connections. Compliance with international safety standards such as cUL, cULus, EN 60950-1, TUV, UL 60950-1, and CE provides confidence in quality and safety.

This converter is ideal for engineers designing power supply solutions requiring compact footprint, stable dual output voltages, and reliability in industrial, laboratory, telecommunications, and manufacturing contexts. The Cosel SUTW101212 ensures optimized power conversion with low ripple noise (200mV Pk-Pk) and high switching frequency of 1900kHz.

Isolated dual output design provides +24V and -24V DC outputs simultaneously. Operates over a wide input voltage range from 9V to 12V DC. Maximum output current of 450mA supports various power requirements. Compact DIP package designed for PCB mounting with through-hole pins.

Efficiency up to 86%, ensuring reduced power loss and heat generation. Operating temperature range from -40°C to 85°C for reliable performance in harsh environments. Built-in remote ON/OFF control functionality for convenient integration.

Output voltage adjustable externally within ±22.8V to ±25.2V DC range. High isolation voltage of 500V AC for enhanced safety and noise reduction. Compliance with multiple standards including cUL, cULus, EN 60950-1, TUV, UL 60950-1, and CE markings.
