TDK-Lambda DC/DC Converter Dual Output 12V dc to -12 V dc, 450 mA, Through Hole, 10 W, 7-Pin DIP Package CC10-1212DF-E

TDK-Lambda CC10-1212DF-E DC/DC Converter is a compact, high-quality dual output power supply unit delivering 12V dc and -12 V dc outputs at 450 mA, with a maximum output power of 10 W. The device is housed in a durable DIP package enabling through-hole mounting, providing ease of installation in various printed circuit boards.

Built for demanding environments, it supports a wide operating temperature range from -40°C to 85°C and features input voltage compatibility from 11.4V dc to 12V dc. The isolation voltage is rated at 500V ac, ensuring protection and noise reduction in sensitive electronic systems.

The CC-E series by TDK-Lambda is known for combining lightweight metal casing with reduced electromagnetic interference (EMI), making it well-suited for industrial, laboratory, manufacturing, broadcast, and process control applications. Its compact size and high efficiency of 86% contribute to energy savings and system reliability.

The output voltage adjustment range of ±15 V dc allows customization for specific application needs while maintaining stability and performance. Compliance with international safety standards including UL CSA 60950-1, EN 60950-1, NEMKO, cULus, and CE assures users of its quality and safety.

The device supports a maximum input voltage of 12V dc and a minimum input voltage of 11.4V dc. It delivers a maximum output power of 10 W with a high efficiency of 86%. The unit features a robust 7-pin DIP through-hole mounting package, measuring 35.56 mm in length, 17.52 mm in width, and 8.5 mm in depth.

Designed for operation within a temperature range from -40°C to 85°C to suit various environmental conditions. It provides electrical isolation of up to 500V ac, enhancing device safety and signal integrity. The output voltage adjustment range is ±15 V dc, allowing flexibility for diverse applications.

Complies with major safety and quality standards including UL CSA 60950-1, EN 60950-1, NEMKO, cULus, and CE certifications. This converter series is suitable for process control, broadcast, test and measurement, and general industrial use.

This product is manufactured in Japan to high-quality standards and is ideal for incorporation in electronic equipment requiring stable dual voltage DC power sources with moderate power capacity.
