Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 15μH ±20% 5.69A Idc DR125-150-R

Free Delivery in India | Lowest Global Shipping Charges

Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 15μH ±20% 5.69A Idc DR125-150-R

Name: Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 15μH ±20% 5.69A Idc DR125-150-R
Brand: Eaton
SKU: 395601
Price: 1.26 USD
Availability: InStock



Category Surface Mount Inductor Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	6mm
Length	12.5mm
Model	DR125-150-R
Depth	12.5mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	15μH
Standards/Approvals	RoHS
Package/Case	0125
Maximum DC Current	5.69A
Pin Count	2
Maximum DC Resistance	29.8mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

Constructed with a ferrite core for high efficiency and magnetic shielding.
Rated for a maximum operating temperature of 125°C under strict RoHS compliance.
Wirewound design ensures stable inductance with ±20% tolerance.
Compact surface mount style with dimensions of 12.5mm length, 6mm height, and 12.5mm depth.
Maximum DC resistance is low at 29.8mΩ to minimize power loss.
Available on a reel packaging for mass production insertion efficiency.
Suitable for high frequency applications up to 100kHz.
Designed for use in electronics including computers, DVD players, LCD panels, and DC-DC converters.

Product Description

The Eaton DR125-150-R is a shielded wirewound Surface Mount Inductor designed with a high power density ferrite core construction. It features a nominal inductance of 15μH with a tolerance of ±20%, and is capable of handling a maximum DC current of 5.69 amperes. This inductor is surface mount type with a package case of 0125 and dimensions measuring 12.5mm in length, 6mm in height, and 12.5mm in depth, making it compact for integration into various electronic devices.

With automatic shielding, this inductor reduces electromagnetic interference effectively, suited for high efficiency power applications. It operates reliably within a temperature range from -40°C to 125°C and complies with the RoHS standard to ensure environmental safety. The maximum DC resistance is 29.8 milliohms, maintaining low power loss in circuitry.

The DR125-150-R series inductors are ideal for industrial and commercial uses such as computer motherboards, DVD players, portable devices, LCD panels, and DC-DC converters including buck, boost, forward, and resonant converter topologies. They provide effective noise filtering and are essential for power supply stabilization in electronic systems.

Constructed with a ferrite core for magnetic shielding and high core efficiency. Wirewound inductor type providing stability and durability during operation. High maximum DC current rating supports demanding electrical loads.

Low DC resistance reduces heat generation and improves system efficiency. RoHS compliant ensuring product safety and environmental compliance. Available on reel for automated surface mount assembly processes. Designed for operation up to 100kHz frequency for versatile electronic applications.

Eaton’s DR series inductors are reliable components for integration in industrial electronics, telecommunications, and power management systems. This product is made in China and held to high manufacturing standards with new condition guaranteed.
