STMicroelectronics Audio Power Amplifier, 8-Pin SOIC Package, 0.38W Output Power TDA2822D
Specifications
| Country of Origin | China |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.25mm |
| Length | 5mm |
| Model | TDA2822D |
| Width | 4mm |
| Output Power | 0.38W |
| Mount Type | Surface |
| Series | TDA2822D |
| Maximum Operating Temperature | 150°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 3V |
| Amplifier Type | Audio Power Amplifier |
| Amplifier Class | Class A-B |
Key Features
- Operates in Class A-B amplifier configuration for optimal audio performance.
- Single-channel audio power amplifier suitable for headphone and speaker applications.
- Supports supply voltage range from 3V to 12V ensuring versatile use cases.
- Compact SOIC surface mount package with dimensions of 5mm length, 4mm width, and 1.25mm height.
- Wide operating temperature range from -40°C up to 150°C suitable for diverse environments.
- Filterless and capless amplification features integrated to improve power efficiency.
- Packaged in 8-pin layout suitable for efficient PCB mounting and integration.
Product Description
STMicroelectronics TDA2822D is a high-performance Audio Power Amplifier IC designed for headphone and low power audio amplification applications. It operates in a Class A-B amplifier configuration delivering clean and efficient power output at 0.38W, making it ideal for small speaker systems and headphone drivers.
The device comes in a compact 8-pin SOIC package, measuring 5mm in length, 4mm in width, and 1.25mm in height, enabling easy surface mount integration onto printed circuit boards. It supports a robust operating voltage range from 3V to 12V and can operate reliably in harsh environmental conditions ranging from -40°C to 150°C.
This amplifier integrates filterless and capless amplification features designed to optimize power efficiency and reduce external component count, simplifying circuit design. Its single channel output makes it well-suited for audio consumer electronics, portable audio devices, and embedded sound systems.
Manufactured in China, the TDA2822D complies with no specific industry standards or approvals, representing a cost-effective solution for general audio amplification needs without automotive certification requirements.
Operates as a Class A-B amplifier ensuring balanced audio fidelity and efficiency. Capless and filterless design reduces external components and board footprint. Single channel output optimized for headphone and speaker driving.
Compact surface mount SOIC package eases PCB design and assembly. Wide voltage input and extended temperature range allows flexible application environments. Industrial and consumer electronics applications including Audio Amplifiers.
Reliable audio performance with minimal external filtering requirements. Explore a wide selection of audio amplifier ICs and related electronic components on EnvMart for industrial, laboratory, and consumer audio applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TDA2822D amplifier delivers an output power of 0.38W.
It supports a supply voltage range from 3V to 12V, allowing for versatile use cases.
This model comes in a compact 8-pin SOIC package with dimensions of 5mm in length, 4mm in width, and 1.25mm in height.
The amplifier operates reliably in a wide temperature range from -40°C to 150°C.
It features a single channel output, making it suitable for headphone and speaker applications.
It operates in a Class A-B amplifier configuration, which ensures optimal audio performance.
This amplifier is designed for surface mounting, facilitating easy integration onto printed circuit boards.
The amplifier features filterless and capless amplification, which reduces the need for external components.
It is suitable for headphone and low power audio amplification applications, including consumer electronics and portable audio devices.
The TDA2822D is manufactured in China.
This model has a pin count of 8, suitable for efficient PCB mounting and integration.
The maximum supply voltage for this amplifier is 12V.
