Weidmüller OMNIMATE SL Series Pluggable Terminal Block, 5-Contact, 3.5 mm Pitch, 320 V, 17 A, Polybutylene 1607530000

Weidmüller 1607530000 OMNIMATE SL Series Pluggable Terminal Block is a high-quality connector designed for industrial and electronic applications requiring efficient PCB connectivity. Featuring 5 contacts with a 3.5 mm pitch and a single row configuration, this terminal block supports rated currents of up to 17 amperes and voltages up to 320 V. Its housing, made from polybutylene terephthalate, provides excellent electrical insulation and mechanical durability, suitable for demanding environments.

The male connector with straight orientation and solder wire connection method ensures reliable and stable electrical contacts, complemented by a solder pin length of 3.2 mm, compatible with PCB thicknesses of 1.6 mm and 2.0 mm. Designed for vertical flanged mounting, this terminal block accommodates wave soldering assembly techniques.

Safety and compliance are assured with CSA and cURus standards certification, making it suitable for industrial, manufacturing, automation, and electronic applications. The bright orange color aids in easy identification among other connectors, reducing assembly errors.

The OMNIMATE SL series represents a cost-effective, space-efficient solution optimized for printed circuit board usage with fully enclosed sides and optional polarizing pins to prevent mismatched connections. It supports both rising clamp screw terminals and tension clamp harness connectors.

Features a polybutylene terephthalate housing for durability and insulation. Designed with a male connector and straight orientation for easy integration. Supports wire connection via solder method ensuring secure joints.

Rated for 320 volts and a current capacity of 17 amperes for robust performance. Compact dimensions of 24.5 mm width, 7.5 mm depth, and 3.2 mm solder pin length for space-saving use. Complies with CSA and cURus standards ensuring safety and quality.

Part of the OMNIMATE SL series offering cost-effective and space-efficient solutions. Suitable for vertical flanged mounting and wave soldering processes. Color-coded orange housing improves visual identification in assemblies.

This Pluggable Terminal Block is ideal for electronics manufacturing, industrial control systems, automation, and other commercial applications requiring secure and standardized electrical connections on printed circuit boards. Explore our comprehensive range of Weidmüller OMNIMATE SL series components and connectors for compatible accessories and panel mounting solutions available at EnvMart.
